larger than the outside diameter of the tubing. Under concrete/asphalt slab, sleeved CSST must be buried in accordance with all local codes.

Where does CSST need to be bonded?

The CSST must be permanently bonded directly to the grounding electrode system of the electrical service of the home in which the CSST is installed.

Does black CSST need to be bonded?

In accordance with section 310.3 of the Fuel Gas Code, you probably don’t need any special bonding if you have black CSST. When building officials have asked the manufacturer how much distance is required, the manufacturer has left it up to the building official.

Does gas piping need to be bonded?

Bonding is required to prevent a possible electric shock hazard for persons that may be in contact with the gas piping and other grounded metallic building components. A stock hazard can result if these systems are energized at different levels of electrical potential.

Can TracPipe be ran outside?

The TracPipe is uv rated, so it can go outside.

How much does it cost to bond CSST?

How Much Does It Cost? As with most electrical repairs the cost can vary significantly based on many factors, but a good rule of thumb would be between $150 – $500 for most single-family homes in Central Iowa.

How do I strip flash shield?

Cut: Place cut-end of FlashShield tubing into Side 1 of the stripping tool up to the tube stop. Close the stripping tool around tubing. Begin rotating the tool back and forth on the CSST (3 – 5, 200º twists) while applying pressure until the blades cut through all 3 jacket layers.

Does black gas pipe need to be grounded?

3 Answers. According to National Electrical Code, the pipe has to be bonded. However, it can be bonded using the grounding conductor serving the equipment that uses the gas.

Does CSST gas pipe need to be grounded?

CSST Gas Lines Must Be Grounded Contact a licensed electrician who will ensure it is properly bonded and grounded. The reason for this safety precaution is that a nearby lightning strike could cause the systems in your structure to become electrically energized.

Does my boiler need earth bonding?

There is no requirement for bonding a boiler; it is earthed. Supplementary bonding is not required in a kitchen. However, this is a favourite with plumbers because they do not understand.

Article first time published on

Can TracPipe fittings be concealed?

Can TracPipe® CounterStrike® fittings be concealed? Yes. TracPipe® CounterStrike® fittings have been tested and listed by CSA-International for use in concealed locations.

Are TracPipe fittings reusable?

They are designed to be used on original installation only. It’s unsafe for reuse if there’s additional handling and removal of the connector.

Can TracPipe be buried in concrete?

If you use Tracpipe, it can be buried directly in the screed.

Can you bury gas Tite?

For installations buried underground, concrete, asphalt or embedded in concrete, Gastite flexible gas piping must be routed in a non-metallic watertight conduit, which has an inside diameter at least 1/2 inch larger than the outside diameter of the tubing. No mechanical joints are permitted within the conduit.

What is flash shield plus?

FlashShield+™ flexible gas piping delivers industry leading household fault current and lightning protection. It utilizes a metallic-shield within its protective jacket to handle hi-voltage risks associated with lightning strikes as well as dielectric jackets for lower voltage associated with household fault current.

Can Csst be used in walls?

CSST is flexible, so it easily snakes through walls and around obstacles without the need for multiple joints. With rigid pipe, routing around each obstacle requires a joint that needs to be fitted and checked for leaks.

How much does it cost to bond a water heater?

The bonding wire is usually a heavy copper wire fastened with brass clamps at one end to the cold water pipe and at the other end to the hot water pipe. The parts cost only about $10 and can be installed in just minutes.

Does black iron pipe need to be grounded?

Systems that are made up of black iron (steel) pipe are bonded to prevent electrical shock in case the pipe comes into contact with an electrical circuit. But, the newer yellow corrugated stainless steel tubing needs to also be grounded to prevent it from exploding if struck by lightning.

What needs earth bonding in a house?

2 Answers from MyBuilder Electricians These should connect to 1) water installation pipes 2) gas installation pipes 3) other installation pipework and ducting 4) central heating and air con systems 5) exposed metallic structural parts of the building.

Is supplementary bonding still required?

Residual current devices (RCDs) – A sensitive switching device that trips a circuit when it finds an earth fault. … You may need supplementary bonding for rooms containing a bath or shower, except where all circuits in the room are RCD protected and the main bonding is up to the required standard.

What is earth bonding?

The earth creates a safe route for the current to flow instead of causing electric shock. The purpose of bonding is to reduce the risk of electric shock if you find yourself touching separate metallic parts when there is a fault somewhere within the electrical installation.

Should a natural gas meter be grounded?

SoCalGas® always encourages customers to make energy efficient choices. … However, grounding to SoCalGas gas pipes, meters or service risers (as pictured) is prohibited (California Electrical Code, Article 250), because it can accelerate metal loss from steel equipment that may result in hazardous gas leaks.

Is TracPipe bonded?

The Tracpipe® gas piping system shall be bonded in accordance with the National Fuel Gas Code, NFPA 54/ANSI Z223. The piping system is not to be used as a grounding con- ductor or electrode for an electrical system.

Can you run flex gas line in attic?

Most homes have gas lines in their attic, walls & basements. CSST flexible gas lines in the attic are a prime candidate for damage from lightning strikes. Especially if they are not protected with Bonding to ensure electrical energy is carried away from the pipe (versus carried by the pipe).

Can flexible gas line go through floor?

Three- or six-foot long and accessible: The flexible connectors can’t go through walls, floors or ceilings, nor can they be concealed. The flexible connector length usually is limited to 3 feet except for gas ranges and clothes dryers.

Can you reuse flared fittings?

DO NOT reuse connectors, fittings and valves; they are designed for use on original installation only. Removal of connector and additional handling may damage connector making it unsafe for reuse. Overall this is to help prevent leaks caused by dirt, debris, and damage that may prevent good connections.

Can you reuse Wardflex fittings?

A: WARDFLEX is superior to other CSST fittings in many ways: The double-seal metal-to-metal and metal-to-gasket increases reliability and reduces potential for leaks. The reusable gasket allows for fast reassembly without replacing any components, including the gasket.

Do gas dryers need Teflon tape?

The cheap Teflon tape that comes in the blue package is for water pipes. You can’t use it on gas. There’s a different kind of PFTE tape that comes in a yellow package. The yellow tape is thicker, harder, and has more tensile strength than the blue stuff.
