Armoured cables and cables having an earthed metal sheath suitable for use as a protective conductor may be buried directly in the ground without further protection, except against corrosion, which may be negated by the provision of a plastic covering. Surface fixed cables may be fixed to permanent structures.

Can you run armoured cable above ground?

The cable can be run above ground, so long as it is kept away from anything that may damage the wire. … To achieve this, and stop rodents from destroying the wire, install it at height with cleats. If you’ll be running the cable underground then you’ll need to lift the floor to make enough space and depth.

Do you need to earth armoured cable?

An armoured cable is often used with a minimum of three conductors, one being used as a cpc for the circuit, the other two being Live and Neutral. Two-core armoured can be used but the armouring itself needs to be used as the cpc so needs to be continuous, so is earthed at both ends (else it wouldn’t be continuous!).

Can armored cable be exposed?

It is permitted for indoor or outdoor service, feeder, or branch circuits and can be exposed or concealed.

Does armoured cable need to be in a conduit?

Whilst the weight and rigidity of armoured cables can make them hard to handle and time-consuming to terminate, they are essential in applications where unarmoured cables may be prone to damage and require containment protection, i.e.: conduit or trunking.

Can armoured cable be fixed to a fence?

Yep, they sometimes do. But the point of clipping the cable to the fence (if it happens to be going the right way) rather than, say, shallow dig it is to make it visible and keep it away from potential sources of damage such as digging. The cable would ideally be fixed to, say, the top of the gravel board – ie.

How far down does armoured cable be buried?

The NICEIC manual recommends 600mm down or more with tape or tiles 150mm above the cable in sifted soil or sand.

Can you use Armoured cable outside?

Construction of an SWA Armoured Cable SWA cables are heavy, which makes them extremely difficult to bend; therefore they are most suited to underground cabling or fixed to outdoor walls using cable cleats.

Can armored cable be used outdoors?

The interlocking metal tape armor Type MC cable is required to have a bare or insulated equipment grounding conductor in addition to any other conductors within the cable. … These cables can be installed either indoors or outdoors and in exposed and concealed locations.

Where can armored cable not be used?

Armored cable cannot be used for direct burial in earth. With minor exceptions, armored cable is also not permitted to be used in hoists or elevators, storage battery rooms, any hazardous locations, in commercial garages and in theaters or similar locations.

Article first time published on

Does Armoured cable need RCD protection?

swa’s steel armour is NOT accepted as sufficient protection for the cable when buried. there is no requirement to afford rcd protection to cables buried outside. socket circuits that COULD be used outdoors MUST have RCD protection, when this is a domestic installation.

Does Armoured cable need to be buried UK?

Ideally the cable should be buried at a sufficient depth so as not to be easily hit by say a pick or shovel. it should also have marker tape buried above it close to the surface so that anyone digging above the cable finds this first and it should warn them that a cable is below.

Do I need to earth both ends SWA?

Yes, the armour should be earthed at least at the “supply” end. This ensures that anything that penetrates the cable (saw, drill, etc) will be earthed before the live cores are reached, and is therefore less likely to become energised.

Can armoured cable be buried in soil?

Armoured cables and cables having an earthed metal sheath suitable for use as a protective conductor may be buried directly in the ground without further protection, except against corrosion, which may be negated by the provision of a plastic covering. Surface fixed cables may be fixed to permanent structures.

Can you run armoured cable along a fence UK?

You can run the cable as it is and just clip it to the fence. The armourings inside will provide mechanical protection. There is no set height for this, so if you want to hide it at the back of your beds, that’ll be fine. as miles says as long as its in armour.

Can SWA cable be directly buried?

SWA is fine direct in soil in a back garden. Minimum 500mm depth afaik (foot traffic only). Have to bury a SWA cable in the garden underneath the lawn, about 10m long.

How can I run electricity from my house to my shed UK?

1. Find an electrician. …
2. Think about WHY you need to power your shed. …
3. Work out where the cable will run. …
4. Prepare the cable trench. …
5. Check you’re happy with the plan. …
6. Let the electrician do their work.

Can Armoured cable be buried in concrete?

If burying in concrete then according to the regs a few inches will do (to a depth unlikely to sustain impact damage) but in general stick to half a metre and cover with sand and warning tape and you won’t go wrong!

What cable do I need to run power to a shed?

One of the most frequently asked questions is what outdoor electrical cable do I need to power my shed? The answer is armoured cable.

How do I run power to my shed above ground?

Running electrical lines above ground is usually not recommended for a shed. Instead, run wiring out to the shed via a specialized underground conduit. But be wary of installing this without identifying all other possible utility lines in its path.

Can I run electric cable outside?

You can run electrical wire outside to nearly any location. Although some types of electrical cable do not have to be enclosed in conduit for outside installation, enclosing any exposed cable is a good idea. Schedule 40 polyvinyl chloride (PVC) conduit for electricity is gray and is rated for sunlight resistance.

Where can armored cable be used?

Armored cables are used in applications where cables will be exposed to mechanical or environmental damage under normal operating conditions. These applications include power circuits in industrial plants, commercial buildings, processing plants and central and substation utility applications.

Can AC 90 be used outside?

The biggest difference between the two cable systems is that MC has full size ground wire while AC uses a combination of the jacket and a thin bonding strip or wire to function as the equipment ground. … Now AC cable cannot be used in exterior or damp locations.

Can you install BX cable outside?

A chief distinction between BX and NM is that BX can achieve grounding through the outer metal casing. This casing needs to be attached to metal boxes. Another distinction is that some types of BX cable can be installed in exposed locations, either indoors or outdoors.

What size Armoured cable do I need for a summerhouse?

An armored 6mm cable direct in the ground is rated 44A. So in term of your 32A supply the 6mm cable is absolutely fine. No reason for unnecessary additional costs.

How far down does electrical conduit need to be buried?

In general, bury metal conduits at least 6 inches below the soil surface. You may also run them at a depth of 4 inches under a 4-inch concrete slab. Under your driveway, the conduits must be below a depth of 18 inches, and under a public road or alleyway, they must be buried below 24 inches.

Can Armoured cable be submerged in water?

Armoured cables should not be installed in locations where they are liable to be immersed in water, such as on the floor of a crawl-way duct where water may collect in puddles. The ends of armoured cables should be kept sealed until ready for termination, to reduce the risk of water ingress.

Should shielding be grounded?

The shield must be grounded to be effective. The shield should be electrically continuous to maximize effectiveness, which includes cables splices. In shielded signal cables the shield may act as the return path for the signal, or may act as screening only.

When should you use armored cable?

To put it in context, typically armoured cables would be used when you require the cable to be buried directly underground, for outdoor installation or in tunnels. There may be instances where the ground is opened up again, and in the process, a spade or mechanical excavator may hit the buried cable by accident.

What is the difference between Armoured cable and flexible cable?

Unlike cable shielding, which is often braided or a foil wrap design, the armor shield is wound around the cable, giving it a corded, corrugated appearance. … And some companies’ armored cables, such as Mencom, use a woven flexible stainless-steel design. A big difference in the three designs is in how they are ground.

Does SWA need to be buried?

SWA is direct burial and doesn’t need any additional mechanical protection. Depth is as deep as it needs to be.
