The size of your duct work depends not just on the size of your entire house but also on the size of each individual room. Thus, one needs to gauge the square footage of the entire house as well as that of all the different rooms in order to decide duct work sizing.

What size air duct do I need?

To calculate the required equipment size, divide the HVAC load for the entire building by 12,000. One ton equals 12,000 BTUs, so if a house or office needs 24,000 BTUs, it will take a 2-ton HVAC unit. If you get an uneven number, such as 2.33 for a 28,000 BTU load capacity, round up to a 2.5-ton unit.

How many CFM can a 12 inch duct handle?

The rule of thumb for a 12 inch duct is 715 cfm. You would need a 20 inch duct to handle 2000 cfm.

What size ductwork do I need for a 3 ton unit?

Multiply the tonnage, 3.5, by the total BTU per ton and this will give you the total BTU rating. Multiply 6 x 42 to determine the duct size of 252 square inches The clear are of the duct must be at least 252 square inches This measurement also includes the opening in the floor at the bottom of the return.

How many CFM is a 12x12 duct?

12″ Duct12″ CFM8×12400 CFM10×12550 CFM12×12680 CFM14×12800 CFM

What size duct is needed for 1000 cfm?

Air flow – q – (Cubic Feet per Minute, cfm) (m3/s)Rectangular Duct Sizes (inches) (mm) x (mm)Friction Loss (inH2O / 100 ft duct) (Pa/100m)1000 (0.45)10 x 14 12 x 120.151300 (0.59)12 x 140.151400 (0.63)12 x 150.151700 (0.77)10 x 22 14 x 150.14

What size ductwork do I need for a 5 ton unit?

Using this approach, two 20-in. x 25-in. return grilles will be the right choice for a five-ton HVAC system in order to actually deliver 2,000 cfm back to the blower without causing the return to hemorrhage.

How do I know what size flex duct I need?

• Measure the length and width of the room where the flex duct will be supplying the air. Multiply the length and width together to get the square footage of the room. …
• Figure out the amount of CFM that is required for the room. …
• Use the online duct calculator (see References) and calculate the needed flex duct size.

What size duct do I need for a 2.5 ton AC unit?

For instance a 2.5 ton system (Approximately 400 CFM per ton) would require (2) 14” flexible return ducts or (1) very short flexible 18” duct to move the 1000 CFM required by the 2.5 ton system.

Can flex duct be used for return air?

Flex duct is widely used for return air in commercial air conditioning systems. Flex duct is able to withstand a certain negative pressure of return air. When installed properly, a flex duct is a reliable and convenient ductwork solution. Flex duct often gets a bad rep because of airflow issues.

Article first time published on

What happens if ductwork is oversized?

Using oversized ducts will erode the system’s efficiency, while undersized ducts won’t carry the necessary volume of air. Balanced airflow. To maintain neutral pressure in the HVAC system and throughout the house, the duct system must deliver and return a matching volume of air.

Does register size matter?

Unless you are severely undersizing your register, the noise is really the only issue. So a bigger register will not help cool or heat your room better. Putting the register in a better location and making sure the air is shooting out in an efficient manner and at an efficient angle is key.

How many CFM do I need for 200 square feet?

Room Size:CFM (At 2 ACH)How many CFM for a 100 sq ft room?27 CFMHow many CFM for a 200 sq ft room?53 CFM

How many CFM is 100 square feet?

Example: For residential bathrooms up to 100 sq. ft. in area, HVI recommends an exhaust rate of 1 cfm per square foot. A bathroom is 6′ to 10′ or 60 square feet.

What is the good rule of thumb in sizing Ductworks?

Determining the Right Duct Size When you hire a professional to install your ductwork, they’ll often size your HVAC ducts using a rule of thumb that states an air conditioner with one-ton capacity should be installed for every 500 square feet of air-conditioned floor area.

How many CFM do I need for 1000 square feet?

Total area of home (square feet)Continuous ventilation rate1,000 square feet50 CFM2,000 square feet100 CFM3,000 square feet150 CFM

How big should return air vents be?

Large Returns There usually are fewer return vents, but they are much larger. A typical supply vent is 4 by 10 to 12 inches and a typical return vent is 16 by 20 inches or larger. Houses often have two or more return collecting points, each with a filter, which join before re-entering the heating unit.

How much return air do I need for a 4 ton?

You can never have to much return air, as a HVAC contractor you want no less than 144 square inches per ton. Regarding the 3.5 TON VS 4 TON The average square foot per Ton is 400 so say the house is 1600 SQFT a 4 TON unit should work great.

How many CFM are in a ton?

The airflow is measured in cubic feet per minute (CFM). 350 to 400 CFM per ton of cooling is required for proper air conditioning system operation.

How do you calculate CFM for duct size?

1. CFM = FPM x Duct Cross Sectional Area.
2. FPM = 4005 x √.45.
3. FPM = 2,686.
4. CFM = 2,686 x Duct Cross Sectional Area.
5. A (Duct Cross Sectional Area) = X (height in feet) x Y (width in feet)
6. A = 1.07 sq. feet.
7. CFM = FPM x Duct Cross Sectional Area.
8. CFM = 2,686 x 1.07 sq. feet.

How much CFM is needed for a room?

One cfm is needed per square foot (1 cfm/sq ft) of floor area. This is the average air quantity required for a room or an entire building.

How many CFM is a 4 duct?

Reviewing the chart, a 4” pipe will convey 395 CFM at 4500 FPM. This means that a 4” pick-up on a machine will use 395 CFM from the filtering system; or, if you know that a machine will require approximately 400 CFM to remove the waste, you should use a 4” pipe for that purpose.

How many CFM is a 5 ton unit?

A 5-ton system should have have 2,000 cfm, a 6-ton system should have 2,400 cfm, and so on and son. Measuring how much airflow measurements deviate from that math is a quick way to diagnose airflow issues in a residential duct system.

Can you have to much return air?

Can an air return be too big? No, an air return cannot be too big, except in extreme cases where a closed room is temporarily under negative air pressure. Return vents maintain air pressure, filter out debris, and are critical to the efficient operation of any HVAC system.

How do you measure HVAC duct size?

Measure the end of a square or rectangular duct each way to determine the size. If the duct fitting inside the wall transitions to a circular duct, measure inside the circular duct from top to bottom. Repeat this at the remaining grills and ducts throughout the house.

Can I install my own ductwork?

With a little help, you can do your own air duct installation. The typical rate for an hvac dealer to do it is about $50/hour.

How far can you run flex duct?

Flexible duct shall be supported at manufacturer’s recommended intervals, but at no greater distance than four feet. Maximum permissible sag is 1/2 inch per foot of spacing between supports.

What is the average cost to replace ductwork?

The average cost to replace ductwork is $1,400 to $5,600, depending on the home’s size. Air duct replacement costs $25 to $55 per linear foot or $270 to $500 per duct for a crawl space, attic, or basement. New ductwork installation costs $2,400 to $6,600 for a house without HVAC ducts.

Can you use dryer duct for HVAC?

if you live in a humid area there might be a chance of condensation around the metal which might put moisture in the batt insulation making it useless as insulation, but there are other types of insulation you could use near the ducts… but basically you’ll be okay to use what ever type you‘d like.

Can ducts be too large?

The Ducts Are Too Large Not much. … This is what happens when your air ducts are too big for your system. Your system pushes air into the ducts, but the ducts are too large for it to build up any sustained amount of air pressure, and thus a “forced air” system doesn’t have any force.

What happens if my ductwork is undersized?

Ducts that are undersized will increase the static pressure, which will result in excessive noise as air moves through the system. It is often loud enough to be distracting, so it will not be difficult to overlook and should be addressed, as undersized ducts overwork the heating unit.
