Find your gas valve. … You need to turn the valve to the off position for at least three minutes.Once you have had the valve at off for a few minutes, switch it over to pilot setting.You will need a match that is lit. … Set the pilot valve to the on position.

What do I do if my pilot light won't light?

If your pilot light won’t stay alight, it might be the thermocouple. Sometimes dust buildup collects on the thermocouple and blocks the sensor. Try cleaning the thermocouple and then relighting the pilot light. If it continues to go out, the thermocouple might need to be replaced.

How do you reset the pilot light on a heater?

1. Step 1: Turn off your furnace. …
2. Step 2: Locate your gas valve. …
3. Step 3: Hold down the red button. …
4. Step 4: Light the pilot light. …
5. Step 5: Let go of the button. …
6. Step 6: Turn your gas back on. …
7. Step 7: Turn your furnace back on.

Why does the pilot light go out on my gas heater?

If the pilot light goes out, the thermocouple senses the drop in temperature and signals for the gas valve to close. If you have a faulty thermocouple is the most common reason that your pilot light is malfunctioning. Over time your water heater will collect dirt, dust and other kinds of debris.

Why is my pilot light not staying lit on my furnace?

Some common causes include issues with the thermocouple and pilot tube. The thermocouple detects the pilot light via sensors. … A dirty pilot tube can also prevent the pilot from staying lit. If the pilot tube is dirty, let the furnace cool down and turn off the gas.

How do you know if you have a bad thermocouple?

If you can’t get the flame to light at all, and you’re sure the gas is on, there’s probably an obstruction in the pilot tube. If the flame lights and goes out when you release the gas control knob after holding it in for the recommended 20 to 30 seconds, that’s the sign of a thermocouple malfunction.

Can I relight the pilot light by myself?

If your pilot light goes out, your furnace will not be able to produce heat because its burners will not ignite. Often, homeowners can relight the pilot themselves.

Can you clean a thermocouple?

Yes, you can clean a thermocouple, but the task must be done with a light touch. Remove the thermocouple from the process assembly, using a steel wool or emery cloth, lightly clean the tip removing any build up.

How much does it cost to replace a thermocouple?

It costs $150 to $250 to replace a thermocouple. It checks to make sure the pilot light is on. It will shut the gas off if it’s not.

How much does it cost to relight a pilot light?

Most service providers will charge a standard fee per visit that typically covers the cost to relight a gas water heater. This service call price can range from $80 to $100.

Article first time published on

Does gas turn off when pilot goes out?

This is because all modern gas appliances with pilot lights have a fail-safe device that closes off the gas to the appliance in the case when the pilot may go out. … If the pilot light goes out for any reason, the current stops, the valve closes, thus preventing any gas from leaking.

Should the pilot light always be on in a gas heater?

Most furnaces with electronic ignition have a device called a hot surface igniter. … The difference is that the flame is only lit (by an electronic spark) when your furnace is ready for a heating cycle. When the pilot light is not needed, it is completely off, saving you money on gas.

How do I know if pilot light is out?

1. Locate the front cover panel on your furnace. It should be a little door that’s easily visible. …
2. If your pilot light is on, it should be easy to see – your eyes will be drawn to the little flame.
3. If you don’t see a flame, your pilot light is out.
4. If there is a flame, check the color.

How do you bypass a thermocouple?

1. Move the tilts switch wire aside.
2. Remove your thermocouple from the heater using an 8mm wrench.
3. Pull the valve housing aside using your 13mm socket wrench. …
4. Remove the valve using your pliers. …
5. Put your thermocouple back into position.

Can I replace a thermocouple myself?

The No. 1 cause of pilot lights that won’t stay lit is a worn-out thermocouple. It’s easy to replace and a new one costs $5 to $10. Rather than trying to unfasten the thermocouple inside the water heater’s burning chamber, it’s easier to remove the whole burner and thermocouple assembly.

What causes a thermocouple to go bad?

Changes in temperature can cause regular expansion and contraction in metal, which will cause thermocouples to weaken over time. After enough time, metal fatigue can cause a thermocouple to break. … If thermocouples start to give out unusual readings, it may be suffering from metal fatigue.

How long do thermocouples last?

How to Tell if You Have a Bad Thermocouple? Thermocouples can last up to 10 years if properly installed and maintained, while furnaces can last 15-20 years, although either may wear out sooner in multifamily units.

How do you clean a pilot light?

1. Cut off the gas to your furnace. …
2. Remove the pilot light and thermocouple assembly. …
3. Use your pliers or wrench to remove the pilot light and thermocouple from the bracket.
4. Using the wire brush, brush away the carbon buildup and soot from both components.

What can you clean a thermocouple with?

The best way to clean your thermocouple is to use either a piece of steel wool or the coarse side of a sponge to gently clean off any soot or other remnants. You can use a pencil eraser to clean between the threads of the screw that connects the thermocouple to the control valve of your system.

How much does a standing pilot cost?

Usually it is $1 and change. So you pilot can be costing you $7 to $10 per month. Propane is a little bit different. Since propane is done by the gallon, the numbers are different.

Who should I call to light a pilot light?

Instead, leave the house and call your local gas company or 911.

How can I get my gas turned back on?

You can use the online “Fumigation – Start Gas Service” form to request the turn on, or call 800-743-5000 (residential) or 800-468-4743 (non-residential). Typical appointment times are in four hour blocks. Note that: The Notice of Re-entry must be posted before PG&E will turn your service back on.

Can I turn my gas back on myself?

Once the valve is turned off, do not turn it back on by yourself. It must be turned on by a gas company technician. The gas company will likely perform a pressure test on the system and relight all pilot lights in the house as part of turning the gas back on.

How much gas does a pilot light use?

How much gas does a pilot light require? Most pilot lights consume around 600 BTUs of gas every hour. If you leave your pilot light on for an entire day, it would roughly consume 14,400 BTU’s every day.

How do you unclog a pilot tube?

1. Remove the cover plate at the bottom of the water heater. …
2. Turn the gas control to the “Off” position. …
3. Locate the pilot tube. …
4. Clean the pilot hole by brushing it with a stiff wire brush.

How do you fix a yellow pilot light?

If you notice that you pilot light is burning yellow instead of blue, contact Jerry Kelly. The issue can typically be fixed by cleaning out the air intake valve to the pilot light, which should only be done by a professional who knows how to access and repair the part.

What is a pilot orifice?

A water heater pilot orifice controls the flow of gas to the pilot. Gas. orifices are engineered to strict tolerances. A tiny amount of debris. will interfere with the operation of the pilot light.
