Solenoid Kit 4L80E 85E Shift Solenoids EPC TCC and Wire Harness.

How many transmission solenoids are there?

Of the transmission solenoids, there are three main types: the transmission shift solenoid, the lockup solenoid, and the transmission control solenoid.

How many gears does a 4L80E transmission have?

There are five gears in a four-speed overdrive transmission: First, Second, Third, Overdrive, and Reverse. All of these gears have a clutch assembly that uses springs to keep the gear disengaged.

How many speed sensors does a 4L80E have?

Speed Sensing Two-speed sensors can be found on the 4L80E transmission, and these sensors serve as a turbine input speed and output speed, respectively.

Will a bad shift solenoid always throw a code?

Will a Bad Shift Solenoid Throw a Code? … Ignoring a warning light or code being thrown by a faulty transmission shift solenoid can lead to serious problems, such as running your vehicle in the wrong gear for your speed and conditions. This can then lead to your transmission overheating and breaking down.

What are the symptoms of a bad transmission solenoid?

• Unpredictable Gear Shifts. One of the most common sign that one or more of your transmission solenoids are going bad is unpredictable gear shifts. …
• Inability to Downshift. …
• Delays In Shifting.

Is there a fuse for shift solenoid?

Most modern vehicles have some sort of transmission control module that monitors the transmission through various sensors, such as the shift-position sensor and the transmission speed sensor. Additionally, the TCM and solenoid wiring are protected by fuses.

How much is solenoid replacement in a transmission?

TypeCost RangeSingle$15 to $100Pack$50 to $300Labor$120 to $400Total (Pack)$250 to $600

How do you diagnose a bad shift solenoid?

1. Delayed gear shifting.
2. You can’t downshift, and your engine continues to rev even when applying the brakes.
3. Your transmission gets stuck in neutral.
4. Shifting gears become rough and choppy.

Does a 4L80E need both speed sensors?

Premium Member. Yep, NO front sensor is needed with our harness.

Article first time published on

How much power can a 4L80E handle?

In short, Performance Automatic yields a 4L80E engineered to handle 700+ horsepower and comparable torque.

What vehicles came with a 4L80?

4L80-E/4L85-EOverviewSuccessor6L90

What's the difference between a 4L80 and 4L80E?

The 4L80 nomenclature denotes that the transmission is a 4-Speed, Longitudinally mounted, and for 8000 lbs. … The 4L80E was designed for vehicles up to 8000 lbs. GVWR and with engines up to 440 ft.

Does a 4L80 need a computer?

The only logical transmission for our 4×4 was the 4L80E four-speed automatic transmission commonly found in 3/4- and 1-ton GM trucks and SUVs. … The only downfall of this swap is that the 4L80E is an electronic transmission that generally requires an additional computer and wiring harness to operate properly.

What is the difference between 4L80E and 4l85e?

The primary difference between the two is the 4L80-E planetary gear sets have four pinion gears as opposed to the 4L85-E gear sets that have five pinion gears.

How do you reset a shift solenoid?

1. Step 1: Turning Key Position. Before resetting the transmission control module, it is necessary to check the key position. …
2. Step 2: Press gas pedal. …
3. Step 3: Keep Waiting. …
4. Step 4: Turning the Key Off. …
5. Step 5: Releasing Gas Pedal. …
6. Step 6: Wait Again. …
7. Step 7: Ready.

Can you replace a shift solenoid yourself?

Replacing a transmission shift solenoid can be done by most any auto repair shop, automobile dealership service center or you can do-it-yourself “DIY”. … NOTE: On some transmission models, the solenoids are part of a solenoid pack. In these instances, you must replace the entire solenoid pack.

Can you clean shift solenoids?

A transmission solenoid valve controls the flow of transmission fluid through the transmission of a vehicle. … Fix this issue by cleaning the transmission solenoid valves, but only attempt this job if you have basic mechanical knowledge and are familiar with your vehicle’s transmission.

What are the signs of a bad transmission control module?

• Unpredictable shifting.
• Trouble shifting into higher gear.
• Trouble downshifting.
• Getting stuck in the same gear.
• Poor fuel economy.
• Check engine light comes on.

What happens when a solenoid goes bad?

Engine Does Not Start When you have a bad starter solenoid, the starter motor won’t work. This means the engine won’t start when you turn on the starter switch or press the start button. However, if your vehicle has an automatic transmission, the engine could sometimes not crank because of the neutral safety switch.

Should I replace transmission solenoid?

The Erratic Shifting of the Gears In the case of delayed or erratic shifting of the gears, it is recommended to look at replacing the solenoids. When the transmission solenoids fails, the transmission system of the vehicle tends to skip gears.

Where is the speed sensor located on a 4L80E transmission?

Sensor is located on the driver’s side of the transmission immediately behind the bell-shaped portion of the housing. It’s held in by one bolt and has a wire running to it.

Where is the speed sensor on a 4L80E?

The transmission connector is located on the passenger side of the 4L60E transmission housing and on the driver side of the 4L80E transmission housing. The vehicle speed sensor is located in the tail shaft housing on the passenger side.

Can a 4L80E handle 1000hp?

Our PERFORMANCE 4L80E series is ideal for street/strip driving and upgrades from a 4L60E/4L65E platform. It’s rated at 1000 RWHP….

What is the strongest GM transmission?

The 6L90 is the strongest of GM’s family of Hydra-Matic six-speed automatic transmissions.

How long does a 4L80E transmission last?

IMHO, the 6.5’s and 4L80E’s are capable of 500,000 miles…

Which is better 4L80E or 6L80E?

“The main difference is that the 6L80E has much more versatile gear ratios. … The 4L80E is more proven because it has been around much longer and more parts are available for it, but the 6L80E has come a long way and they can handle tons of power with a few basic upgrades.”

Is the 4L80 a good transmission?

The GM 4L80E Automatic for Max Power and Good Cruisin’ Overdrive transmissions are great inventions. They allow a car to run deep rear gears for tire-smoking or wheel-hangin’ launches yet still maintain some semblance of highway cruising ability. The problem is durability.

Which transmission is better 4L60E or 4L80E?

Without a doubt the 4L80E is the more powerful of the two transmissions. Vehicles with powerful engines, such as big trucks for towing or high speed cars for racing, require a 4L80E rather than a 4L60E as the power of the engine is likely to break smaller, less powerful transmissions.

How many bolts are on a 4L80 pan?

Matt C nailed it – 16 bolts is the 4L60, 17 bolts is the 4L80.

What transfer case is behind 4L80E?

NP246 Transfer Case- NP8 Fits 98-02 with 4L80E (32 spline)- Bulldog Tough OEM Quality Replacement Unit From The Gear Shop.
