And the standard height for a washing machine outlet box is 42” in our area. So now you have three different numbers. But the important thing is to get the drain, or the drain hose loop in the case of GE’s anti-siphon clip, above the flood level of the rim of the washer tub.

How high should a washer drain box be?

In order for the drain hose on your Top Load washer to function properly, the drain must be at least 30″ up from the floor and less than 8 feet high. In order for the drain hose on your Front Load washer to function properly, the drain must be at least 24″ up from the floor and less than 8 feet high.

What are the dimensions of a washing machine box?

40 DWV pipe. Box Dimensions: 8-3/4″W x 7-1/2″H x 3-5/8″D. Faceplate Dimensions: 11-3/4″W x 10-1/8″H. Easy installation – “Lock & Load” valve mounting system for quick and easy positioning.

What height should a dryer outlet be?

While it depends on local building codes, electrical connections for washers and dryers usually need to be placed less than 6 feet from the unit and 34-36 inches high.

What are the dimensions of a standard washer and dryer?

Size: Traditional washers (and dryers) are 27 to 28 inches wide and 30 to 35 inches deep; height can vary. Plan for 6 inches of space between the machine and the wall and 1 inch between machines.

How far does dryer plug have to be from water?

The only code requirement seems to be the distance with in 6 feet of the dryer or washer – other than that no other requirement.

What kind of box do I need for a dryer outlet?

Make sure you provide an equipment ground and use a NEMA 14-30 receptacle. The box can be metal or plastic. Some form of cable clamp is always required, it’s just that most plastic boxes have an integrated clamp (that finger-trap style door).

How much does it cost to install a washer outlet box?

The price to put in washer and dryer hookups averages between $350 and $600 if they’re placed in an ideal location. If the appliances end up in a spot that’s further from your existing plumbing, you could end up paying anywhere from $700 to $2,000 or more. Washers take a standard 120V outlet.

What is standard dryer outlet?

A 3-prong dryer cord was the standard for dryers prior to 2000. The National Electrical Code currently requires 4-prong dryer outlets in all new home construction. Existing homes may still use 3-prong outlets. The switch to a 4-prong outlet was due to a flaw in the 3-prong outlet design.

Does a washer need a special outlet?

Washer – Washing machines are large appliances that do not require customized electrical hookups, they simply need a 120 volt outlet that can take 3 prongs.

Article first time published on

What are the dimensions of a dryer box?

Dimensions will vary by brand and model, regard these as typical: Side-by-side top-load washers and standard front-load dryers: 27 inches wide, 27 to 28 inches deep and 34 to 43 inches high (per appliance) Stacked (combo): 27 inches wide, 30 to 32 inches deep and 75 inches tall (for the entire unit)

How much height do you need for stackable washer and dryer?

The ceiling height in most homes is at least eight feet (96 inches), and the average height of a stackable washer and dryer is around six and a half feet (78 inches). So, unless you’re trying to install your units in a room with an unusually low ceiling, you should have plenty of vertical space.

What is the standard height of a stackable washer and dryer?

The Chicago Tribune reported that the average size of a stackable washer or dryer ranges from 74-76 inches high, 23-28 inches wide and 27-32 inches deep, while a standard-sized unit is typically 27 inches wide.

What is the standard size of a washer and dryer in cubic feet?

Both standard and high-efficiency top load washers range between 3.1 and 4.0 cubic feet. Front load high-efficiency washers can range from 4.0 cubic feet to an extra large capacity of 5.0 cubic feet. Most front loaders are between 4.2 and 4.5 cubic feet.

Can you put 240v in a junction box?

Can’t do it, not allowed. The junction box cover must be accessible without the use of any tools. (other than the two screws holding on the box cover itself, obviously). However, you can make the junction box be dual-purpose.

Is 10 3 wire heavy enough for a dryer?

10/3 is FINE for the dryer. 12/2 for the washer. Typically a 220v/30 amp Dryer circuit would utilize 10/3 with ground. According to this voltage drop table, it looks like for 100′ run you would want to up-size the wire to #8 copper, to maintain voltage drop less than 3%.

Can a dryer be plugged into a regular outlet?

The answer is no in all likelihood. Most dryers use a 240 volt circuit, while the common domestic containers are 120 volts. If plugged into this outlet, the dryer does not work.

How tall is a washer and dryer?

General Dimensions of Front-Load Washers and DryersCompactFull-SizeWidth24 inches27 inchesHeight34 inches39 inchesDepth (door closed)24 inches*32-34 inches*Depth (door open)42-44 inches*54-57 inches*

What is the height of electrical outlets from floor?

Standard Height for Outlet Boxes The standard height for wall outlet boxes is about 12 inches from the top of the floor covering to the bottom of the receptacle box (or 16 inches to the top of the box).

Does washing machine receptacle need to be GFCI?

There is no specific requirement in the NEC for the washing machine itself to have GFCI protection. Section 210.52(F) requires a receptacle outlet to be installed for the laundry area and it must be supplied by a 20-ampere branch circuit in accordance with 210.11(C)(2).

Are 3 prong dryer outlets safe?

The answer is, “No”, 3 prong dryer outlets are not safe, and the National Electrical Code now require dryers to be wired with a ground wire, i.e. four prong outlet like the one shown below. Any metallic, electrical machine without a ground wire is a potential risk for a nasty electric shock.

Why are there different 220V plugs?

Most US homes are wired with 110-volt breakers and power outlets (which actually range from 110 to 125 volts). However, some larger appliances use higher voltage and may need 220 outlets. There are two main types of 220 outlets, and they require extra precautions and special equipment for wiring.

Are dryer outlets 220 or 240?

Most electric dryers are rated at 240 volt. The nominal voltage is 240 volt, but homes may have 208V, 220V, or 240V power supply. Any appliance that is rated for 240 volts can also be used on a 220V or 208V outlet.

How hard is it to put in a washer and dryer hookup?

Installing a washer and dryer in an existing laundry room with all the necessary plumbing, electricity and vents already in place is typically a fairly straightforward project requiring only basic skills and tools and taking less than an hour.

Can you install a washer and dryer without hookups?

You don’t need special washer dryer hookups in your apartment to use a washer dryer combo, just a standard (in North America, anyway) 120-volt electrical outlet and a connection to cold water. … You can also use your sink to hook up your washer dryer combo, usually with the help of a portability kit.

Does adding a laundry room add value?

While it’s true that remodeling an existing laundry room won’t really do much for your home’s financial value, if you do not have a first-floor laundry room today, you may be disappointing potential buyers and detracting from your home’s value.

What is a 220 plug?

220-volt outlets are the most powerful plugs that you’ll find in most residential homes around the United States. These plugs are meant for ovens, dryers and other high-powered appliances that you simply can’t power with a standard 110V outlet.

Should a washing machine be on its own circuit?

Your laundry room should have a dedicated circuit of at least 20 amps. If you have a gas dryer, both your washing machine and gas dryer may be plugged into the same outlet. If you have an electric dryer, it will need its own dedicated 20-amp, 220-volt circuit.

Do washers come with power cords?

The Washer should come with an electrical cord and drain hose. The Dryer will need a power cord and vent hose. These are not provided since there are two styles of electrical cords ( 3 prong, 4 prong) currently used. … Dryers do not come with electrical cords, and washers don’t come with hoses.

Do washing machines need a water hammer arrestor?

The general rule is that water hammer arrestors are required on all quick closing valves. … But since as the engineer you have no control over the type of hoses used as the washer supply, you would be foolish not to install water hammer arrestors.

Does washing machine drain need a vent?

All plumbing fixtures—including washing machines—must be vented. Improperly vented drains can be sluggish and noisy, and can emit hazardous fumes. Properly vented drains allow the P-trap to do its job: prevent sewer gases from escaping into your home. … location of the vent on the drain.
