OSHA defines a “steep roof” as any roof with a rise/run ratio over 4:12 (18.43 degrees).

What does 4/12 mean on a roof?

Roof slopes are most commonly defined by the rise-over-run ratio. If a roof slope “rises”, say, 4 inches when measured 12 inches along the bottom of a horizontal roof truss, the roof slope is said to be 4:12; i.e., 4 inches of rise per 12 inches (one foot) of run.

What's the steepest roof pitch?

Steepest standard pitch A 9/12 roof pitch (36.37 degrees). is the steepest standard slope.

What percentage is a 4/12 roof?

Roof Slope (Standard Roof Pitch)Roof Slope (Degrees)Roof Slope (Percentage)4:1218.43°33.33 %5:1222.62°41.67 %6:1226.57°50 %7:1230.26°58.33 %

What angle do I cut for a 4 12 pitch?

What angle is a 4 over 12 pitch? Roofs with a pitch of 4/12 are approximately 18.4 degrees, depending on how exact you’d like to be in your measurement.

What is the rise on a 4/12 pitch roof?

A 4/12 is a roof slope that rises by 4 inches for every 12 inches across. This forms an angle of 18.5° between the horizontal section and the roof, and creates a gentle incline that is seen as a midpoint between a low-pitch and medium-pitch roof.

Is a 4/12 roof pitch good?

4/12 is quite typical. Anything under 3/12 is a low pitch roof. Anything above 6/12 is a steep roof pitch since it becomes harder to walk on the roof.

What is the ideal slope for a roof?

For metal panel roof systems, NRCA recommends slopes of 1/2:12 or more for structural panel systems and 3:12 or more for architectural panel systems. For asphalt shingle, clay and concrete tile, metal shingle, slate and wood shake and shingle roof systems, NRCA recommends slopes of 4:12 or more.

What is a 2% roof slope?

PitchGrade (slope)Degrees1/4:122.1%1.2°1/2:124.2%2.4°1:128.3%4.8°2:1216.7%9.5°

How steep is a 12 pitch roof?

Roofs with a pitch of 12/12 are approximately 45 degrees, depending on how exact you’d like to be in your measurement. Check out our roof angle chart for more examples of the exact angles (expressed in degrees) of common roof pitches.

Article first time published on

Is a 5/12 roof pitch steep?

The 5/12 or 5 on 12 roof pitch are most common types of residential roof pitch which are a sloping surfaces with an angle of usually 22.62° degrees steepness of a roof with it’s vertical rise of 5 inches over its 12″ or 1 foot horizontal distance or run in building construction.

Do steep roofs last longer?

Yes, the steeper the roof, the longer the roofing material will last. Because water runs off the roof more easily, the roof covering will dry faster. And during the hottest part of the year when the sun is higher overhead, a steeper roof will absorb less solar radiation than a flatter roof.

How long is a 4/12 pitch roof?

4/12 or “4 in 12” roof pitch or slope, generally roof rafter length will be 15.81 feet or 4.82m long for 30 feet span.

How tall is a 4/12 truss?

A 4 / 12 pitched roof simply means that the roofline rises 4 feet in height for every 12 feet of depth. For example, if the peak of your roofline is 18 feet from the outer wall where it starts, and the wall as a 4 by 12 pitch, then that means that the roof would be 6 feet in height above where it started at the wall.

What is a 4/12 pitch?

A roof that rises 4 inches for every 1 foot or 12 inches of run is said to have a “4 in 12” slope. … The slope ratio represents a certain amount of vertical rise for every 12 inches of horizontal run. For example, a “4 in 12” slope can be expressed as the ratio of 4:12. A “6 in 12” slope is expressed as 6:12.

What is the disadvantages of a steep pitched roof?

Steep Roofing – Cons The biggest downside with this type of roof is that roofing materials can be harder to install compared to a low slope roof. Pitched design allows for less usable space inside a building.

What does a 4 pitch roof mean?

A 4/12 roof pitch indicates the roof rises 4 inches in height for every 12 inches, as measured horizontally from the edge of the roof to the centerline. The gentle slope of a 4/12 pitch roof falls on the cusp between low-pitch and moderate-pitch.

How do I calculate roof pitch?

1. First, you need to measure the run of your roof. …
2. Next, you need to figure out the rise. …
3. Now, divide the rise by the run. …
4. Then, divide 1 by your tangent.
5. Finally, multiply this result by 180/π and you’ve calculated your roof pitch!

Is a 3/12 roof pitch good?

Any roofs up to 3:12 are generally considered “low slope.” In the residential arena, we see lower slope roofs as part of the home’s architectural design. … Then, when you get into roofs of 3:12 or greater pitch, most other metal roofs can be used and that generally is the pitch requirement for asphalt shingles as well.

What pitch Should a roof be UK?

A typical roof pitch in the UK for a traditional house will be 40°-50° but at the extreme can go up to 70° (above 70° would actually be called a wall!) Part of the choice of pitch is down to the architect and different period homes will have different pitches which are more “aesthetically pleasing” to the designer.

How far can a 2x6 rafter span without support?

2-grade 2×6 joists can span up to 10 feet 9 inches from beam to beam when spaced the standard 16 inches apart with a maximum live load of 30 inches per square foot.

Is birdsmouth cut necessary?

A lot of force is transferred down the length of the rafter, and the seat cut on the birdsmouth transfers that force directly to the top plate. … In general, while the ripped-strip installation does eliminate the need to make two cuts for the birdsmouth, it’s debatable whether there are any real labor savings.

Is a truss roof cheaper than a cut roof?

When looking at the price differential of trussed rafters and loose timbers, a truss solution, although using smaller timber sections will generally, for the supply element, be slightly more expensive. … On the majority of structures, a Trussed Rafter roof will be more affordable than a site cut roof.

What kind of roof do I need for a 2 12 pitch?

A pitch of 2/12 is the minimum for shingles made of asphalt, so your roof just barely makes the cut-off for one of the most popular roofing material options. Resilient asphalt shingles lie much flatter to the substrate than slate, tile and concrete, which keeps water from being easily blown under them.

Can you Shingle a 1/12 pitch roof?

Asphalt shingles are not recommended for a flat roof, as shingles cannot be properly sealed if a roof has a pitch less than 2/12 inches, leading to water leaks.

What angle is a 5/12 roof?

Roof Pitch Degree Table1-124.76°4-1218.43°5-1222.62°6-1226.57°

Can you Shingle A 2 12 pitch roof?

While roofs with a 4/12 pitch and steeper are ideal, the minimum roof pitch for shingles is 2/12. A roof with a 2/12 pitch can safely use shingles by incorporating additional layers of underlayment around the eaves.

Is a 6 12 pitch roof steep?

The 6/12 roof pitch is by far the most common residential roof pitch. It is steep enough to shed water quickly while also being what we refer to as “walkable”.

Is a higher pitch roof better?

Fewer snow worries: Even without cold roof systems, a steep roof generally is better inside a snowy environment. … Ice will melt more easily on the steep slope and prevent the build-up of ice dams or patches which may force moisture down into the roof.

What are standard roof pitches?

The most commonly used roof pitches fall in a range between 4/12 and 9/12. Pitches lower than 4/12 have a slight angle, and they are defined as low-slope roofs. Pitches of less than 2/12 are considered flat roofs, even though they may be very slightly angled.
