Stagger the shiplap boards so that the end joints are spread out along the wall or ceiling randomly. If you stack seams on top of each other, you’ll create an eyesore that draws your eye to the dark lines of the jointed ends. Building pros agree that staggering seams provides a better looking aesthetic.

Does shiplap have to be staggered?

It doesn’t really matter how you stagger the boards. And just work your way down. The only part about the windows was the top and bottom. I had to trim a board smaller right above the window and right below.

How do I make sure shiplap level?

To start off, you’ll want to make sure to hang your first board perfectly level. After nailing up the first board and making sure it’s perfectly level, you can take the next board and stack it tight to the one above it. This will keep things level all the way to the bottom.

Should I start shiplap from top or bottom?

You can start applying shiplap either at the top or at the bottom of your wall. If you start at the bottom, gravity will work for you. If you start at the top, you’ll have to prevent each board from falling before you nail it in place.

How do you hide seams on shiplap?

Before plywood and drywall, builders would line rooms in shiplap to keep them warm and dry, then cover it with a layer of muslin or cheesecloth and wallpaper to hide the shiplap’s seams.

How do you stagger wood siding?

Installing Siding Siding boards usually come in uniform lengths, so the best way to achieve a random stagger pattern is to cut the first board of each row a different length before installing it. You can often get great stagger patterns by using the off-cut from a row you just finished to start the next one.

What is the spacing between shiplap?

Spacing the Boards: Enlist spacers to create uniform gaps (typically 1/8 inch) between each board. You can use any type of spacer you’d like, such as the edge of a carpenter’s square or tile spacers. Make sure that you position each board using the same spacer so the boards appear evenly spaced.

Do you fill nail holes in shiplap?

For primed shiplap, since you’ll be painting it, you can fill in nail holes with a wood filler. Once you sand down the nail holes you filled in, paint over for a seamless look.

Do you put baseboard over shiplap?

Keep your baseboards, and install shiplap boards that are equal to or have a shallower depth. This way, your shiplap can rest atop your baseboards and won’t stick out. Use whatever shiplap you want and ignore differences in depth where the planks meet the baseboard.

How do you do a corner in shiplap?

To install around windows, doors, outlets and such, cut holes in the shiplap boards using a jig saw to enable it to fit around the obstacle. Caulk all the corner seams and verify all nail holes are filled. Sand all of the walls smooth, prime and paint. Lastly, install floor and ceiling trim.

Article first time published on

Does shiplap expand and contract?

True shiplap boards are wooden boards that have a rabbited edge on either side. … One of shiplaps best qualities is that because it is wood, it expands and contracts. This keeps it from cracking, unlike drywall or plaster, which can form hairline fractures when forced to expand or shrink.

Can you hang shiplap without drywall?

If don’t already have drywall installed, you do not need it as a base for affixing shiplap. You can install shiplap directly to your studs to save on time, money, and mess.

Can you have too much shiplap?

As much as we love shiplap, there can be a time and a place when there is too much shiplap. When you want to fully decorate the walls with shiplap, it is best to stick with soft, neutral colors and limited texture.

How high should shiplap be on wall?

Give some thought to how high you want your trim. So 1/3 or 2/3 of the wall will look better than half of a wall. It won’t be exact, but try to get close. I wanted mine to go a bit higher, but then it would have impeded with the electrical outlet, towel racks, and light switch.

How do you fill gaps in shiplap?

Use Caulk To Cover Up Mistakes If you cut a board slightly short or if there are gaps between your trim and shiplap, caulk can fill in those gaps without showing any evidence of a mistake. Although you don’t want to overdo it on the caulk, it can be very helpful, especially for beginner DIYers.

Do you put trim around shiplap?

Install your faux shiplap before anything else in the room – meaning baseboard, crown, and trim. … If you have trim, very carefully notch out your shiplap with a saw and use wood filler/caulk to fill in the remaining gaps.

Do you caulk around shiplap?

The edges of the shiplap wall need to be caulked (with paintable caulk) wherever there is molding and then they need to be “cut in” with the paint brush. For my wall, we caulked the gaps along the inside wall corners (where we installed quarter round molding), the floor molding, and the top crown molding.

Do you have to finish shiplap?

Final Thoughts on Shiplap It goes up easier, the planks don’t bow like wood can because they’re made of MDF, it has the groove already set which means less room for error, and it comes in a perfect finish, which means you don’t necessarily have to paint it.

Why does shiplap have a gap?

The milling process for edging shiplap boards is to rabbet edges to create a tight and secure joint. The top edge of each board laps over the bottom edges of adjacent boards creating a flush joint. Often, a small gap is left between the boards to give a wall a sense of linear structure.

Should you paint shiplap before installing?

If you’re installing new shiplap, paint it prior to installation. It will be far easier to paint the edges before the shiplap is up on the wall. … If the shiplap was already installed, paint it like wall (with a roller and cut in with a brush), taking extra time to paint the gaps and shiplap grooves with a small brush.

How do you stagger boards?

1. Lay your first row of wood planks about 1/2 inch from the wall. Nail it or glue it down. …
2. Start your second row at the end of the first row. …
3. Place an end remnant at the beginning of the third row, where the second row ended. …
4. Alternate the three row patterns across the floor.

Should siding seams be staggered?

Stagger the siding end laps so that no two courses (rows of panels) are aligned vertically, unless separated by at least three courses. Always overlap joints away from entrances and/or away from the point of greatest traffic. This will improve the overall appearance of the installation (Fig. 37).

How do you stagger James Hardie siding?

It’s best to stagger the joints in each successive course to avoid noticeable patterns. Butt joints in adjacent courses should be spaced apart by at least two stud bays for 16-inch, o.c. framing or one bay for 24-inch, o.c. framing.

What does it mean to stagger planks?

When racking or staggering planks, you want to lay down the pieces as randomly as possible to avoid the formation of step patterns and H-joints. … An H-joint occurs, for example, when an end joint in the first row planks coincides with an end joint in the third-row planks.

Where do you put your nails on shiplap?

Place a nail through the top and bottom of each shiplap board where it crosses a stud. Use adhesive to glue the board down first or ask a partner to help you hold it in place.
