The electric relay in a furnace is responsible for relaying electrical power to the heating elements and the blower motor inside the furnace cabinet. The heating elements provide the heat to warm the air, and the blower motor sends this warmed air through the ductwork.

How do you know if your heater relay is bad?

1. Fan does not work at all, so no air comes out of the vents.
2. Fan only works on some speeds and not others.
3. Fan only works on the highest speed.
4. Fan runs all the time and can’t be controlled with the fan switch.
5. You see smoke coming out of the vents.

What is a heat relay on a thermostat?

Relays – Thermostats communicate with the heating and cooling equipment via relays. For example, the “W” wire turns on heating, and the “Y” wire turns on cooling. If the wires in the thermostat are correctly and snugly connected, you may have a faulty relay switch.

What is a heater relay in a car?

The blower motor relay is the electrical switch that is used to supply the power for the vehicle’s blower motor. The blower motor is the component responsible for pushing air through the vents of your vehicle’s heating and air conditioning systems.

Why will a blower run on the on position and not on auto?

Other Blower Fan Won’t Run Problems The fan will run and blow warm air but only in FAN or FAN ON mode – delivering heat – but NOT in AUTO mode. This is a bad temperature sensor in the unit; replace the fan limit controller.

Can AutoZone test a relay?

After conducting a simple electrical test, you can indicate if you need to replace an ignition relay. AutoZone has the solution for replacing relays at an affordable price so you can be back on the road in no time.

Why does my heater fuse keep blowing in my car?

The three causes from the most common to the least common are: An electrical device has failed. If a wiper motor or power lock solenoid have fried and melted on the inside, it might start drawing too much power in an attempt to keep working. This overloads the circuit causing a short and a blown fuse.

What are the symptoms of a bad blower motor?

• Poor or Airflow from Air Vents. This will be the first and most obvious sign your blower motor has a problem. …
• No Airflow At All From Vents. …
• Skyrocketing Energy Bills. …
• Strange Noises When You Turn on the Heat. …
• Overheating Blower / Weird Smells.

What causes blower motor relay failure?

In most cases, a blower motor resistor fails due to corrosion or overheating. Sometimes, the mechanical resistance to the motor rotation causes an excessive electric current that can overheat and prematurely damage the blower motor resistor.

What does a car blower relay do?

In a blower motor, the relay supplies the power that allows the fans to circulate warmed air. Essentially an on/off switch, the blower motor relay’s reactions start and end the heating process in HVAC systems by controlling the flow of current between the power source and the motor.

Article first time published on

How do I know if my blower motor relay is bad?

If you have a faulty blower motor, you may experience low airflow from the vents, even when the fan is on high. There will be no air coming from the vents if your fan isn’t working due to a bad blower motor resistor.

When using a 10 Wrap multiplier the reading on the meter must be?

By volt-amperes. U 15, When using a 10-wrap multiplier, the reading on the meter must be. Divided by 10.

Why is my furnace clicking but not turning on?

The pilot light or ignition sensor is usually the most common issue when your furnace will not ignite. This is typically the problem if you can hear your furnace click on but it does not fire up. … Then, remove the front panel to find the ignitor or ignition sensor. This is typically located near the burners.

Does the fan have to be on for the heater to work?

Keeping your fan on AUTO is the most energy-efficient option. The fan only runs when the system is on and not continuously. There is better dehumidification in your home during the summer months. When your fan is set to AUTO, moisture from cold cooling coils can drip and be drained outside.

Why won't my heater fan come on?

Inspect the Wires in Your Furnace Make sure that the power cord hasn’t melted or a fuse hasn’t been blown. … If unplugging and plugging your fan back in again doesn’t work, check the fuse box. A surge in electricity may have overloaded your system, and the breaker has popped. Check your fuse box for popped breakers.

Is there a fuse for the heater blower?

Many vehicles have two fuses for the blower motor, one in the interior fuse block and the other under the hood. … The blower motor is usually under the dashboard on the passenger side.

How much does a blown fuse cost?

Cars run on electricity as well as gas, and almost all of it runs through fuses. Learn where they are, how to spot a blown fuse, and how to replace them. It takes about five minutes, costs about $1, and it’ll save you the hassle of a trip to the repair shop.

How much do relays cost?

How Much Does a Relay Cost? An aftermarket relay usually costs around $50 to $250. Prices can vary depending on various factors, like its brand, quantity, product fit, and condition. Labor costs for this type of replacement usually range from $30 to $60.

What is a faulty relay?

If your starter relay has gone bad, the electrical signal will never make it from the battery to the starter motor. As a result, your engine won’t turn over – no matter how many times you turn the key. A faulty relay often produces an audible clicking sound when you turn your car.

How do you know if your starter went out in your car?

Something sounds off. One of the symptoms of a bad starter is a clicking noise when you turn the key or push the start button. However, a starter can die without making any sound at all, or it may announce its impending death with whirring and grinding noise—so listen up!

How do you test a blower relay on a heater?

Connect a test light or multimeter to the ground (black lead). Turn the ignition key to the on position (engine off), and remove the relay. Using the probe, test all terminal sockets in the relay connector. Two of the four should have power.

Can you drive without a blower motor?

Your car’s blower motor is not only necessary for the operation of your air conditioner. Without a functioning blower motor your engine runs the risk of overheating. … Start car and see if blower motor works. If fuse blows again, check for loose circuits.

Why is no air coming out of my car vents?

Here are some of the most common causes of why air doesn’t flow out of your vehicle’s vents: Your air intake is clogged, meaning that air isn’t getting in from the outside at all or isn’t circulating properly. There is a blown fuse in the ventilation system. Electrical issues such as a bad relay.

What causes a relay to fail?

In fact, the life of a relay is essentially determined by the life of its contacts. Degradation of contacts is caused from high in-rush currents, high- sustained currents, and from high voltage spikes. … Relays can also fail due to poor contact alignment and open coils.

Can a relay drain your battery?

A failed ECM power relay can also cause a battery drain or dead battery. If the relay shorts it can leave power on to the computer, even when the vehicle is turned off. This will place a parasitic drain on the battery, which will eventually cause it to go dead.

Can a bad relay cause a short?

Relay Safety The wrong relay can cause a short or a power surge that can damage your vehicle’s electrical system. … If the relay is damaged internally, it can cause burning or melting of wiring. Also avoid modifying the relay in any way.

Why does my blower motor fuse keep blowing?

Blown fuses If the blower motor relay develops any sort of problem that hinders its ability to properly limit and distribute power, it may cause the blower motor fuse to blow. Any sort of electrical spikes or excessive current from a bad relay will blow the fuse and cut power in order to protect the system.
