In its simplest form, a trench drain provides an elongated surface for water to drain from a specific area, such as a driveway, beneath an un-guttered roof edge, sidewalk or similar area where water tends to collect.

Do I need a trench drain?

An especially deep French drain will be necessary if water has moved into the basement. Also referred to as a footing drain, this drain extends along the home’s perimeter to gather water before it moves into the basement.

What is trench drainage system?

Trench drain systems are surface drainage systems designed to manage surface water that can cause safety hazards and damage pavement and property. At ACO, we primarily offer grated trench drainage systems because of their superior design features when compared to grated pit and pipe systems.

Where do you put a trench drain?

Some of the facilities that use trench drains are roads, highways, bridges, loading docks, pool surrounds, ports, commercial kitchens, sidewalk areas, driveways, car parks, and airports – basically all facilities where the quick and frequent removal of surface water is necessary.

What's better French drain or trench drain?

While French drains deal with water that’s underground, trench drains divert excess water away from the surface. … These drains are great for managing excess rainwater and stormwater in concrete areas such as parking lots, sidewalks, and driveways.

How much does a trench drain cost?

The average cost to install a trench drain is $30 to $150 per linear foot, depending on the grate and channel material (plastic, metal, or concrete). Trench drains are set into driveways, patios, concrete slabs, or between pavers with a flush grate surface that catches water in a channel.

Do trench drains work?

When it comes to draining driveways or outdoor areas, trench drain provides an excellent option to remove excess water from an area. … It works well to help protect areas where erosion may be an issue by slowing down the flowing water and diverting it to another area.

How long should a trench drain be?

A: Proper trench drain installation requires it to be installed in concrete. A minimum of 4 inches around the entire trench drain is required. More than 4 inches is required to achieve greater load ratings.

How deep is a trench drain?

Dig a Trench The trench should be about 18 inches deep and 9 to 12 inches wide. French drains need to have a slope of at least 1 percent, so the force of gravity will work for you. This means that the drain should slope down a total of at least one inch for every 10 feet of pipe.

What do I need for a trench drain?

Dig a trench that is 18 inches deep and 9–12 inches wide. Lay water-permeable landscaping fabric in the trench, followed by 3 inches of gravel. Lay your perforated drain pipe in the trench, cover with an additional 3 inches of gravel, and cover the drainage ditch with rocks, soil, or stones.

Article first time published on

Why do trench drains fail?

There are common reasons as to why and how a trench drain system can fail. Most often those reasons consist of poor maintenance, incorrect or improper drain system, grating, and/or installation for the application.

Why do French drains fail?

Over time, a French drain may become clogged. Tiny soil and clay granules slip through the pores of the landscape fabric and gradually build up inside the pipe. Another common cause of French drain clogs is root intrusion from grass, shrubs, and trees.

What is the difference between a channel drain and a trench drain?

Trench drains may also be called channel drains and are an above-ground drainage solution. … Aside from what we’ve listed here, the difference between a French drain and a trench drain is that a French drain is used for water that is underground while a trench drain diverts excess water from a surface.

How much should a French drain cost per foot?

According to Fixr, the average French drain costs $4,500. An exterior drain located fairly close to the surface could cost as little as $1,000, or $25 per linear foot on average. Drains installed under your basement floor could cost $2,000 or more. Expect to pay $60 to $70 per linear foot for installation.

Whats better than a French drain?

If you have a negative sloped yard (which slopes toward your foundation), a surface drainage system is a better choice than a French drain. Sloping of more than 1”-1-1/2” on a 10′ run can result in excessive amounts of water seeping beneath your house.

What is the difference between a French drain and a land drain?

But what do they all mean? Essentially, they are all the same thing. However, French drain more typically refers to the process of removing the surface water by installing a trench and backfilling with gravel. Before there was such a thing as a land drain pipe, this method was called a French drain – without a pipe.

How deep is a French drain?

French drain depth: About 8 inches to 2 feet deep should be sufficient for many water-diverting projects, though related systems, such as those built around foundations and sub-ground living spaces, as well as the bases of retaining walls, may be deeper.

Are trench drains expensive?

A trench drain can vary in cost based on quite a few factors. … For these reasons, trench drains can range in cost between $30 per linear foot to $150 per linear foot.

How deep should drain tile be buried?

If the drain tiles are implemented primarily to protect the foundation from subsurface water, dig the trench up to 6 feet deep. If the primary concern is surface water, a trench only 2 feet deep will suffice. Make sure that the trench extends to a suitable outlet like a ditch, drain field or dry well.

How do I put drainage in my yard?

1. Reduce Your Watering Schedule. …
2. Extend Your Downspout. …
3. Dig a Creek Bed or Swale. …
4. Construct a Rain Garden. …
5. Install a French Drain and/or Dry Well.

How do you drain water away from a house?

1. Clean Your Gutters. This task is both simple and free. …
2. Extend Your Downspouts. …
3. Create A Rain Garden. …
4. Install A Rain Barrel. …
5. Seal The Driveway. …
6. Install A French Drain. …
7. Improve The Grading. …
8. Install A Sump Pump.

Does a French drain need an outlet?

A properly designed French drain system does not require an outlet. The water will simply soak into the soil as it flows along the perforated pipe. In fact, a French drain doesn’t require an inlet on just one end either. You can construct the drain to accept water along its length, and disperse it underground.

Are trench drains sloped?

Channels are externally sloped, where each channel is slightly deeper than the one that precedes it. Channels have slip joints and fasten together to extend runs. Pre sloped concrete trench drains usually come in 3.33 foot (1 Meter Sections).

How shallow can a French drain be?

Add a Layer of Topsoil to Drainage Ditch Dig a trench along the outside of your footing. The trench should be at least 2 feet wide, and can be as deep as 6 feet for a basement or as shallow as two feet for a slab-on-grade home.

How much does it cost to install a French drain?

French drain Installation PricesMinimum cost$2,000Maximum cost$10,000

Can you build a French drain without pipe?

Installing a French Drain Without a Pipe When you omit the pipe from a French drain, you’ve basically got a trench drain. … If your soil drains well, you can simply dig the trench and cover the bottom with 3 to 4 inches of 3/4-inch drainage rock, depending on the depth of the trench.

How do I divert water from my shed?

1. BUILD A BERM, a small hill covered with grass or other plants that will divert runoff around what you want to protect. …
2. ROUTE THE WATER INTO A DRY WELL. …
3. GRADE BROAD SURFACES to direct runoff away from houses, sheds, barns, and patios. …
4. INTERCEPT THE WATER by using a swale, a shallow ditch with gently sloping sides.

How long does it take to install a trench drain?

6 – 8 Hours | A simple french drain installation can be done in one day by a team of professional landscapers barring any complications. 1 – 2 Days | If you rent a trencher and do the project yourself, you can expect it to take up most of your weekend.

Do trench drains freeze?

Made of high quality galvanized steel, LTEC Metal Surface Drains are a great choice for use in all weather conditions. If you are worried about frozen outdoor drains, the metal construction of LTEC Trench Drains is resistant to breaking due to ice buildup and the natural expansion and contraction process.

Does a channel drain need concrete?

Channel drains are made from a variety of materials such as plastic and concrete. The materials of a channel drain are also durable to the point where you don’t have to worry about quick deterioration from something like chemical use.

Do channel drains need to be sloped?

The slope needs to be just right to get water into the drain and away from your home. If your channel is set too high, water can flow backwards instead of into it!
