The deck ledger is the deck floor rim board attached to the house, and it should be positively connected to the floor structure of the main building with bolts or lag screws, not nails.

What is a framing ledger?

The ledger provides much of a deck’s strength; it supports the joists at one end, and it provides stiffness to the framing. … The ledger is made of the same material as the rest of the framing—usually pressure-treated lumber.

Is a ledger board structural?

Attached decks, or ledger decks, are fastened to a building’s wall using a piece of naturally decay-resistant lumber, pressure-treated dimensional lumber, or engineered lumber known as a ledger board; often simply referred to as a “ledger.” It’s usually bolted or screwed to the structural framing inside the adjoining …

What is a ledger in roofing?

The ledger, typically a 2 by 6, is usually designed to hold one end of the patio-roof rafters. Locating and mounting the ledger is normally a fairly easy process; the ledger should be attached before the foundation is built for a deck, patio roof posts, and other structure.

Do you need to attach deck to house?

The deck needs to be connected to, and built off of, a ledger board, which is attached to the wall. … A deck will have to support a lot of weight — furniture, barbecue, people — so this is not the job for nails, or even screws, which do not have the sheer strength for this job.

Is a ledger board a beam?

A ledger board is a horizontal lumber beam attached to an existing wall and used to tie in construction elements such as porch roofs and decks.

Does a deck need a ledger board?

Yes, the deck needs to be tied to the house. You will want to install a ledge board that’s lag bolted to the structure of the house. … And, of course, you should use the appropriate metal hanger to tie the joists of the deck to the ledger board.

How do I attach a ledger board to a house with vinyl siding?

1. Locate the rim joist and mark an outline on the siding where you want to position the ledger board using a tape measure, pencil and chalk line. …
2. Cut away the marked area of siding with tin snips.

What is a ledger used for in construction?

A construction ledger is a record a company keeps to documents all the charges associated with a construction project. The ledger may also contain information about the contractors who worked on the project and the dates that they completed certain tasks.

Should a ledger board be pressure treated?

Installing the Ledger Board The lumber for the ledger and all framing members must be pressure-treated for exterior use. The ledger will establish the height of your deck. This is an absolutely critical connection and must be installed properly to ensure the strength and safety of the deck.

Article first time published on

Can I attach a ledger board to a fascia?

If you own a two-story home, you can tie the ledger into a band joist. Find the band joist by measuring down from the 2nd story window. When you attach the ledger boards to the fascia, they should be held securely with bolts through the wall, or you can use lag screws.

Can a ledger board be two pieces?

The ledger board doesn’t have to be one continuous board. It can be a series of broken sections if it is solidly attached. This will require extra bolts and installing a 2x nailer across the top of the vent to secure the decking along the house wall.

How long are ledger board lag screws?

The most common method is to install ½” lag bolts with washers or carriage bolts with washers. You will usually need the length of the bolt to be at least 4”- 6″ to penetrate through the 2x ledger board, the house sheathing and into the solid house rim.

Can I use structural screws for ledger board?

All structural sheathing materials installed between the deck ledger board and the rim joist shall be positively attached with nails, screws or staples capable of transferring ledger board forces to the rim joists. … Rim joist shall not be end-nailed to floor joists (not shown in Figure 1.)

Can a ledger board be attached to studs?

Mike Guertin (on Instagram @mike_guertin), a builder and remodeler in East Greenwich, R.I., and a presenter at JLC Live, responds: Yes, it’s technically possible to fasten a deck ledger to the narrow faces of 2-by studs rather than to a solid rim joist.

Can freestanding deck be attached to house?

Free-standing doesn’t mean the deck can’t be attached to the house, it just means that the deck frame must be self-supporting. You can still install a couple bolts or screws into the house frame – just as long as the deck has footings all around.

How close can a floating deck be to the house?

For a deck to be free standing it really must be unattached to any other structure like a house. It can be within 3/4″ to 1″ from the siding or exterior of the house and appear like it is connected to an untrained eye but it is truly freely standing from the house.

How much weight can a ledger board hold?

The ledger is 10′ long so every foot of ledger must be designed to carry at least 200 lbs of load.

Does a porch have to be attached to the house?

According to the International Residential Code², adopted by most states, a deck does not need a building permit if it is “less than 200 square feet, under 30” off the ground, does not serve a required exit door, and is not attached to the dwelling“ — if it is freestanding.

What are floating decks?

A floating deck is a deck that isn’t attached to a building and they “float” above the ground. Generally, floating decks are low to the ground and don’t require handrails or even staircases. They are sometimes called “grade-level” or “freestanding” decks because they’re built just above the ground level, or grade.

What is another name for ledger board?

A narrow horizontal board attached to a row of studs to support the ends of floor or ceiling joists. Also called ribbon.

Can a ledger board be 2x6?

Trex recommends 16″ OC at most, 12″ if running the boards diagonally. This is fine for 2×6 spacing. For the ledger, it’s worth replacing so it’s the same size. You might not be able to fully secure the larger hangers to the smaller ledger.

How does a ledger board support joists?

A ledger board — a flat piece of timber anchored to the frame that evenly spreads the load of the joists it supports — is used for the installation of hangers. Joist hangers help to keep joists anchored over time and absorb the forces of the structure above.

What is a beam ledger?

noun. a reinforced-concrete beam having projecting ledges for receiving the ends of joists or the like.

What is General Ledger example?

What is a general ledger with example? There are many examples of a general ledger as they record every financial transaction of a firm. Furniture account, salary account, debtor account, owner’s equity, etc., are some examples.

What are ledgers in scaffolding?

Ledgers are 48mm diameter tubes with a cast wedge fixing device at each end. They are positioned horizontally between two vertical scaffold standards to give the length of the scaffold bay, at platform level. They may also be fitted as a handrail.

Is a freestanding deck better?

A freestanding deck is better than an attached deck in that water remains away from the house. With no ledger attached to the house, water will not become trapped against the house, possibly rotting the side of the house and deck. A freestanding deck gapped away from the house; water will freely flow off the deck.

How do you support a deck without posts?

Instead of using footings, adding a level of gravel will give you the drainage aspect you are looking for. You can then add a frame of wood that anchors in concrete blocks that sit in the gravel, creating your new deck. Concrete blocks won’t rot, making them an ideal option for those who don’t want to use wood.

How much space should be between deck and house?

A proper connection would have a 1/2” to 3/4” gap between the deck construction and the house to allow rain and meltwater from snow to flush through; this prevents rot from forming in the deck timbers, and/or in the adjacent wood of the house framing.

Do I need planning permission for a pergola attached to my house?

You will need planning permission for your pergola if it’s on the front of your house. You will need planning permission for your pergola if it is in a conservation area, on the side of your house between the house and the boundary wall. … Any sort of veranda, balcony or raised platform will need planning permission.

Should a pergola be attached to the house?

Pergolas typically stand on four posts, but an attached design can save space and materials by using your home for support. Securing a pergola directly to the house provides support for that side of the structure, which means only two posts are needed in most cases.
