Both ABS and PVC are used in pipes because they are non-toxic and resistant to abrasion. … ABS stands for acrylonitrile butadiene styrene and PVC stands for polyvinyl chloride.

What is the difference between PVC and ABS pipe?

The Difference between ABS and PVC Pipes The biggest difference between ABS and PVC piping is that ABS pipe contains a chemical called bisphenol A, also known as BPA, and PVC doesn’t. … PVC pipe is more flexible than ABS, while ABS is a bit stronger and can resist a higher shock or impact.

Are my pipes PVC or ABS?

One easy way to tell ABS and PVC apart is that ABS pipes are black and PVC pipes are white. But since pipes aren’t meant to be seen, plumbers are usually more interested in other qualities. For example, PVC is more flexible, but ABS is stronger and more shock resistant.

Why is ABS pipe banned?

Manufacturers used the regrind or recycled plastic as a way to reduce costs and make ABS pipe more competitive with PVC pipe (which has a lower resin cost than ABS); it was generally not done for environmental reasons. …

What does ABS in pipe stand for?

ABS pipe and fittings are made from a thermoplastic resin called Acrylonitrile-Butadiene-Styrene (ABS for short).

Can I use PVC glue on ABS pipe?

You can only use the PVC glue for PVC pipes and ABS glue for ABS pipes. Only at some points, such as when you need to connect two different pipes, you can use it; otherwise, it is prohibited.

Can I glue PVC to ABS?

It is possible to join ABS to PVC, but it is only supposed to be done with a mechanical coupling, not glued. … For the most part, ABS and PVC are not supposed to be glued together. We’ll turn to the Minnesota State Plumbing Code for some background on this topic.

Is ABS pipe legal in California?

[OSHPD 1, 2, 3 & 4] ABS and PVC installations are not allowed.

Why does California use ABS pipe?

(A) Acrylonitrile-butadiene-styrene (“ABS”) drain, waste, and vent plumbing pipe is used to drain or vent wastewater from kitchens, bathrooms, washers, and plumbing fixtures found in the home.

Can ABS pipe be used in commercial buildings?

15 talks about materials, and ABS is OK with the proviso that there must be approved firestopping, and it points out that BUILDING codes will have further restrictions regarding WHERE it may be used. As far as I know, residential up to 3 stories is allowed, commercial has further restrictions on ABS.

Article first time published on

Can I mix black and white drain pipe?

If you’re plumbing in a new drain or vent and have to join two different kinds of plastic pipe, black ABS and white PVC, don’t assume that you can simply glue them together. Most plumbing codes don’t allow ABS pipe to be solvent-welded (glued) to PVC. Check with your local plumbing inspector.

What is the strongest plastic pipe?

Wall Thickness Schedule 80 pipe is designed with a thicker wall. This means the pipe is thicker and stronger, and as a result it can handle higher pressures. You are probably most familiar with schedule 40 PVC pipe.

How long will ABS pipe last?

ABS, black plastic, is the more common inside the home. The NACHI chart gives them a 50- to 80-year lifespan. Both materials will become brittle with age.

Is ABS harder than PVC?

ABS is considerably stronger than PVC when exposed to frigid weather, but is also weakened by exposure to sunlight. So much so that many southern states exclusively use PVC.

What is ABS PVC used for?

ABS is used in drain-waste-vent pipe systems and sewer systems. It is also used as electrical insulation. PVC is also used to produce pipes such as for drain-waste-vent systems and for insulation on electrical cables.

Is ABS lighter than PVC?

The structural difference between the PVC and ABS can also differentiate between the two. The ABS, for instance, is lighter and more flexible. The PVC pipe is stronger, more durable and more rigid. These differences in structures make the pipes usable in different situations.

Should you prime ABS pipe?

Primer: Primer is used to clean and soften the surface of the plastic to ensure a good solvent weld. It’s used with both PVC and CPVC, but is not required with ABS.

What is the difference between ABS cement and PVC cement?

ABS is always black while PVC is white– and easy way to see the difference quickly. … ABS piping are connected through special cement, a one step process, while PVC piping must be primed before cemented together, a two step process.

Is ABS and PVC cement the same?

ABS to PVC cement is only meant to connect an ABS system to a PVC system. An example of this would be an ABS drain system inside of a home connecting to a PVC drain system just outside the building, or vice-versa. That’s the only place that this cement is supposed to be used.

How can you tell if it's ABS plastic?

Look for blue edges around the yellow flame, indicating it’s ABS plastic. Notice a pungent smell if the plastic is ABS. ABS plastic has a very strong, acrid smell when it burns. If the plastic is giving off a stinging smell that’s irritating to your nose, it could be ABS.

What is black plumbing pipe called?

ABS: This black pipe was the first plastic pipe to be used in residential plumbing. Today, many areas don’t allow ABS in new construction because joints can come loose. Check with your local plumbing inspector if you want to use ABS.

What is PEX plumbing?

PEX plumbing is a type of plastic tubing made from high-density polyethylene. Apart from being the newest player in the water supply line game, PEX is also used for radiant floor heating tubing. PEX plumbing has many advantages, including: … Acid-resistant – Unlike copper, PEX can withstand acidic water.

What is the minimum cover for a sewer pipe in ground?

a. Nonmetallic sewer materials shall have a minimum cover of 12 inches. b. Building sewer piping shall be laid on a firm bed throughout its entire length, and any such piping in made or filled in ground shall be laid on a bed of approved materials.

What is the fall on a 4 inch sewer pipe?

For 4-inch PVC piping and a building sewer less than 50 feet long, the minimum slope is 1 inch in 8 feet, or 1/8-inch per foot, and the maximum is 1/4-inch per foot. For sewers longer than 50 feet, the slope should be 1/4-inch per foot.

How often are Cleanouts required?

For long runs of piping, a cleanout is required every 100 feet. This measurement is taken from the highest end of the horizontal drainage piping to the point of connection with the building sewer.

Is PVC pipe up to code?

PVC piping is recognized as acceptable material for DWV, sewers, and potable water services and distribution in all model plumbing codes. These Codes normally identify acceptable products for specific uses based on the ASTM Standard designation.

Why is PVC not used in commercial buildings?

PVC pipes. Polyvinyl chloride (PVC) pipes are commonly used in both residential and commercial buildings. The material does not do well with extended exposure to heat and ultraviolet light, which means it can only be used for indoor and drainage applications.

Can PVC pipe be used in commercial buildings in California?

Plastic pipe can only be used in DWV systems in residential buildings up to five stories high. In commercial construction, plastic pipe is prohibited in all applications. … San Francisco allows plastic water piping but limits it to DWV systems in buildings no more than two stories high.

Can you glue ABS?

= Acrylonitrile Butadiene Styrene. This is a common thermoplastic that is rather easy to bond. … While bonding ABS can be done with various types of plastic adhesives (plastic glues), a few of the most common include cyanoacrylate, 2 component epoxy, structural acrylic, and UV curable adhesives.

Can you separate ABS pipe joints?

You cannot separate them. You will have to cut them off with a hacksaw or a sabre saw. The new sections will have to be fitted to the cut-off stubs, using standard couplings. Being ABS, apparently, you will need special cement made for ABS fittings.

Can you use purple primer on ABS?

Purple Primer, CPVC, PVC, Size 16 oz, For Use With ABS Pipe and Fittings, CPVC Pipe and Fittings, PV. Country of Origin USA. Country of Origin is subject to change. Oatey® purple primer is an aggressive primer for use on PVC and CPVC pipe and fittings.
