P0220 is a diagnostic trouble code (DTC) for “Throttle/Pedal Position Sensor/Switch Circuit “B” Malfunction”.

How do I fix P0120 code?

1. Repairing or replacing the TPS connector.
2. Repairing the wiring as necessary.
3. Replacing the TPS with a new sensor.

Where is the accelerator pedal position sensor?

The TPS is usually mounted on the throttle body (the housing that contains the throttle valve).

How do I fix error code P2121?

1. Throttle body replacement.
2. Throttle actuator motor replacement.
3. Pedal position sensor replacement.

What is a throttle pedal position sensor switch?

Throttle Position Sensor (TPS) Just like the APP sensor, the TPS sensor unit is mounted on the throttle body and converts the throttle body butterfly valve angle position into a voltage signal, which is transferred to the PCM unit.

What does the accelerator pedal sensor do?

The accelerator pedal sensor transmits the position of the accelerator pedal to the engine control unit. Based on this information, the load requested by the driver can be implemented immediately.

What are symptoms of a bad throttle position sensor?

Your engine might stall, idle slowly or misfire when your car is stopped. The car might accelerate itself, hesitate to accelerate, or lack power when you are trying to accelerate. You may also experience difficulty in changing gears.

What is code P2127?

The P2127 code means that the throttle or pedal position sensor switch E has a low input. … The sensor tells the ECU when the gas pedal is depressed and how far it is depressed. When the ECU detects a low input from the pedal, it will trigger the Check Engine Light and the code P2127.

What causes code P2138?

Diagnostic trouble code (DTC) P2138 stands for “Throttle/Pedal Position Sensor/Switch D/E Voltage Correlation.” It is triggered when the vehicle’s engine control module (ECM) or powertrain control module (PCM) detects that the signals from the two throttle position sensors (or two accelerator pedal position sensors) do …

How much does it cost to replace a accelerator pedal position sensor?

The entire replacement process will cost you between $130 and $200. Labor costs don’t have much of a range- somewhere between $70 and $90. But the parts may cost you as little as $50 or as much as $120+. The cost of the sensor itself depends on which model of car you have.

Article first time published on

What happens when you unplug throttle position sensor?

The TPS as we call it is one of the most important sensors on the engine. Without it, the computer has no way of knowing when you push down on the gas or open the throttle. Best it can do it watch some other sensors and make some estimated guesses. On some cars, it may burp just as you unplug it if it’s running.

Is throttle position sensor same as accelerator pedal position sensor?

The accelerator pedal sensor (APS) indicates the position of the accelerator on vehicle models with electronic throttle control. The APS is basically a throttle position sensor (TPS) with a pedal attached.

Will a bad throttle position sensor throw a code?

a faulty tps can set a trouble code in the computer if the voltage value is either not present, sporadic, slow or constant, and this can illuminate your check engine light.

Where is the throttle pedal position sensor switch located at?

The Throttle Position Sensor/Switch is located on the Throttle Body of the Intake Manifold and the Pedal Position Sensor/Switch is part of the Accelerator Pedal assembly. These sensors provide precise input from the driver’s foot in terms of how MUCH power is needed from the engine and, how URGENTLY power is needed.

Where is the throttle position sensor switch?

The throttle position sensor can be found on the throttle body of the intake manifold. Meanwhile, the pedal position switch is usually part of the accelerator pedal assembly.

Can you drive with a bad throttle position sensor?

It is not a good idea to drive with a bad throttle position sensor. Driving your car in this condition can be dangerous because your car might not accelerate properly or could suddenly accelerate without the driver pressing the gas pedal.

Can a TPS sensor be cleaned?

Cleaning the throttle body itself can be done using carburetor fluid and a clean cloth for the removal of light sludge. … During this process, the throttle position sensor should not be cleaned due to the possibility of contamination or wire damage.

What sensor would stop a car from starting?

A crankshaft position sensor (crank sensor) is an important device measuring the engine RPM and tracing the crankshaft position. The car won’t start if the crankshaft position sensor doesn’t work properly. The crank sensor can fail, or its wiring can get damaged. This may cause the car to stall or not start.

Do you have to reset computer after replacing throttle position sensor?

After replacing the throttle body to your engine, if the engine light was on and has a pending code, the code will go away. If the code was a hard permanent code, then the ECM (computer) would need a hard reset. … The engine light will go out and clear all codes as it goes into a learn cycle.

Can a bad throttle position sensor affect transmission?

The Throttle Position sensor measures the throttle position, which is controlled by the gas pedal. It is used to determine engine load and if it fails it can cause automatic transmission shifting problems.

How long does it take to change a throttle position sensor?

The throttle position sensor can be replaced without much trouble. It should not take more than an hour to take it out, replace it with a new one and test everything to ensure it is working.

Can bad throttle position sensor cause no start?

What happens when my throttle position sensor goes bad. When a TPS goes bad, then the car’s throttle body won’t function properly. It could either stay shut or it won’t close properly which is a severe issue. If it stays shut then your engine is not going receive air and it won’t start.

Can you drive with a P2138 code?

We recommend addressing the issue causing P2138 as soon as possible. Your car may have trouble accelerating or go into reduced power mode when this code is triggered, which lets you know it’s not the best idea to drive with P2138.

How do I fix code P2138?

1. Replacing the throttle body motor or throttle body assembly.
2. Repairing or replacing wiring that is associated with the throttle body motor.
3. Replacing the throttle position sensor.
4. Repairing or replacing wiring that is associated with the throttle position sensor.

Does a throttle position sensor need to be programmed?

Code errors can cause your throttle position sensor to work erratically or incorrectly. Otherwise, you’ll need professional software to reprogram your sensor. This job is best done by a professional mechanic. If your sensor just needs repairs, it could be the result of faulty or loose wiring.

Why does the throttle position sensor Get Low voltage?

The voltage of the throttle position sensor can drop below the expected range for several reasons, including the following: A loosely-mounted throttle position sensor. Electrical short on the sensor circuit, either to the ground or to another wire. … Bad or corroded wiring or connections for the sensor.

What is P0123 code?

Diagnostic Trouble Code (DTC) P0123 code stands for “Throttle/Pedal Position Sensor “A” Circuit High.” … It monitors the throttle blade angle and relays this information to the throttle actuator module or powertrain control module (PCM).

How do I fix code P0223?

1. Replacing the throttle position sensor.
2. Replacing the Engine Control Module.
3. Plugging in, repairing, or replacing wiring that is associated with the throttle position sensor.
4. Repairing or replacing the throttle body.
5. Realigning the throttle position sensor.

What causes accelerator failure?

Clogged or dirty fuel filter – A dirty filter, clogged with debris and other impurities will hinder the engine’s ability to receive the proper amount of fuel. … If the fuel pump gives out or becomes clogged, it will be unable to supply fuel to the injectors and may result in poor acceleration, sputtering, or stall outs.

What causes a car not to accelerate?

If your vehicle’s fuel filter is dirty or clogged, this will prevent your engine from getting enough fuel. This can cause your vehicle to experience problems while trying to accelerate. A dirty air filter can also be the culprit. A dirty air filter cannot give the right air-fuel mixture resulting in slow acceleration.

What should throttle position sensor be at idle?

At idle is should be zero or a couple of degrees. Press down on the gas pedal very S-L-O-W-L-Y until the throttle is all the way open. You should see the percentage of throttle opening gradually increase to 100 percent at wide open throttle.
