You may be wondering what an offset kitchen sink is. … Also known as an offset drain kitchen sink, such a sink is preferred because it leaves space to place items and not block the drain. The drain is not located at the center. Instead of the faucet being directly above the drain, the drain is off-centered to one side.

Is offset drain better?

Offset drains make your sink more accessible from top to bottom. You’ll have more space to store your dirty dishes, so water and food debris won’t build up. Below, you’ll have a lot more storage space for a wastebasket, kitchen supplies, and more.

How far can you offset a sink drain?

According to the International Residential Code, the maximum vertical distance between the sink drain and the entrance to the p-trap is 24 inches.

Can sink drain be offset?

Whether it’s because you need to move your sink during a remodel or because your new sink just doesn’t quite fit, the sink drain may end up being offset from the drainpipe in the wall.

Should kitchen faucet line up with drain?

For an ideal installation, the faucet spout should line up with the center of the sink drain so that when the faucet operates, water flows into the drain. This helps avoids many splashing issues, especially with taller faucets.

What is an offset faucet?

This particular faucet is designed for an offset water supply, meaning that your water supply should not align horizontally directly with the shower connections. The shower connection is slightly lower (offset) from the water supply inlets.

Should faucet line up with drain?

Ideally, the flow of water from the faucet should go down the drain. Don’t forget that the faucet usually sits back either on the sink rim if it’s a drop in or a bit farther back it it’s a deck mount. So watch that. … The faucet is the most-used feature in the kitchen.

Can AP Trap be offset?

The P-trap can be offset either way to make them connect. You can purchase a longer tail piece (the vertical pipe that connects to the sink drain) or a longer waist arm (the horizontal pipe that connects the p-trap to the drain in the wall) if needed to make the pieces come together.

Does P-trap need to be below drain?

It is not ideal to have the p-trap below the the exit drain because water gravity has to force the water out instead of it flowing downwards naturally. They both work and have seen it many times. But essentially anything below already creates its own p-trap- so using another is redundant.

Can you offset a toilet?

For the waste water line, an offset toilet flange will allow you to move the toilet a couple of inches in any direction without having to cut a new hole in the floor or reconstruct the waste water pipe. … Additionally, an offset flange may cause a stoppage as the water leaving the toilet will be diverted slightly.

Article first time published on

Can a sink drain go through the floor?

You cannot do that. It is against all rules of common sense, the national building codes of Canada and the US, and almost surely against the local plumbing ordinances you have. A sink needs to be connected to your sanitary sewer. The floor drain will be connected to your storm sewer.

Can a sink drain run horizontal?

Drain piping can be horizontal (1/4” per foot), vertical, or 450- vent piping shall be free of sags and be graded and connected to drip back by gravity to drain pipe it serves.

Can a shower and bath share the same drain?

1:Can multiple bathroom sinks, baths, showers ect share a common drain pipe ? Yes they can and do all the time.

Why does my P trap smell?

A p trap is designed to use water to block the sewer gases from leaking up the drain. If a sink’s p trap dies out this can result in a drain that smells bad. To alleviate this problem pour water down the drain to restore the water barrier in the p trap.

How far should faucet hole be from sink?

The distance between the faucet body (where the water enters the faucet) and the areator is usually 8 to 10 inches for a kitchen faucet. However some oversized faucets have a reach of 11 to 16 inch.

Why is the faucet so close to the back of the sink?

Faucets are at the back so water connections had minimum interference with under-sink storage, and to leave area over sink clear for physical wash access.

How far out should the faucet extend over the sink?

The standard reach for many sink faucets is an average measurement of 5.5 inches deep. It can go up to 8 inches. Are you using your vessel sink to wash hands, shave, brush your teeth, and other grooming activities? If the sink’s bowl is sloped, then a six-inch deep faucet would be best.

How high should tap be above basin?

Wall hung tap ware should have the spout sitting approximately 100mm to 150mm above the basin. When choosing a vanity select one that naturally complements it surroundings while being practical and functional. In smaller bathrooms opting for a wall hung vanity will give the illusion of spaciousness.

Do high arc bathroom faucets splash?

A high-arc faucet does splash, but only when it is paired with a shallow sink, which isn’t advisable. Bathroom sinks that are wider and deeper are ideal for high-arc faucets, so you won’t have more splashing than usual.

How far should faucet hole be from wall?

In this case there should be about 3 inches of space from the edge of the sink to the wall/backsplash. In most cases this will allow at least a one inch rim around the front of the sink. Again, this measurement will depend on the size of your sink as well as your countertop depth.

What is offset bowl sink?

Pros: The term “offset sinks” really refers to two different sink styles: 1) a double bowl, with one full-size and one smaller bowl or 2) a sink whose drain is located near the edge or directly under the faucet, rather than smack in the middle.

Where should drain be in kitchen sink?

Did you ever notice the drain location of the kitchen sinks on the market? The majority of them are either right in the middle of the sink, or the rear center. This design was used by our ancestors thousands of years ago.

Why does a shower require a 2 inch drain?

A 2-inch pipe is the recommended size because showers have a low threshold for flooding, and a 2-inch pipe helps the water drain faster than does a 1 1/2-inch pipe. So, if you are converting from a tub and shower combination to a shower, you’ll likely have to change the drain pipe size.

How close should P-trap be to shower drain?

How far can P-trap be from shower drain? The maximum distance between the shower drain and the P-trap is 5 feet. However, the P-trap should be as close to the shower drain inlet as possible. You should even have the P-trap directly under the shower drain for the best results.

Why do sinks need P traps?

The p-trap under sink plumbing pipe serves the function of capturing a small amount of water inside your drainpipes after the sink is used. This plug prevents sewer gases from coming up the wastewater line and out the sink.

Can you offset a vanity?

If you’re downsizing your existing vanity to make more room for alternative storage, offsetting the sink allows you to scoot the vanity out of the way, making more space for your new furniture without turning a simple remodel into an expensive renovation.

What if new kitchen sink drain doesn't line up with existing pipes?

In general, if the P-trap doesn’t line up with the drain, you can adjust the length and height of your drainpipes by cutting them or simply slipping them in and out of their fittings.

Can you use flexible pipe for sink drain?

Flexible drain parts can be used to quickly connect offset sink drains. … It is possible to cut out the pipes under the sink and install a new sink drain using a 45- or a 90-degree bend to make up the difference, but it may not be necessary for a minor misalignment.

Does a shower drain need a trap?

Do shower drains have traps? … According to regulations, all shower drains are required to have P-traps. This includes all fixtures connected to a building’s main plumbing system. P-traps are curved pipes installed under showers and drains of all kinds.

How do I know if my toilet is a 10 or 12 rough?

If the old toilet is still there, measure from the center of the capped bolts (on the bottom) to the wall (not the baseboard). There should be 24 inches of clearance from the wall facing the bowl and 15 inches on each side as a guideline. If your measurements are between 11.5 and 12.5 inches, it is a 12-inch rough-in.

Why does my toilet moves side to side?

If the flange is a little higher than the surrounding flooring, the toilet becomes raised slightly in the center, allowing it to rock to either side. This problem can develop over time, such as when the wax seal becomes faulty or when a surrounding floor settles a little.
