PSL beams are generally more expensive than glulam, LSL, or LVL beams. … Laminated Veneer Lumber (LVL) is a commonly available engineered product that is manufactured similarly to PSL. Available sizes, strengths, and stiffnesses are similar to PSL but are generally cheaper, making it a commonly specified beam type.

Is PSL or LVL stronger?

PSL beams are generally more expensive than glulam, LSL, or LVL beams. … Laminated Veneer Lumber (LVL) is a commonly available engineered product that is manufactured similarly to PSL. Available sizes, strengths, and stiffnesses are similar to PSL but are generally cheaper, making it a commonly specified beam type.

What is PSL beam?

Parallel-strand lumber (PSL) is a form of engineered wood made from parallel wood strands bonded together with adhesive. It is used for beams, headers, columns, and posts, among other uses. … It is the world’s only commercially manufactured and marketed parallel-strand lumber product.

What is the strongest engineered wood beam?

Power Beam® – 3000Fb – 2.1E – 300F Power Beam® is the strongest engineered wood product (EWP) on the market with design values of 3000Fb – 2.1E – 300Fv.

What type of wood beam is the strongest?

Perhaps the strongest wood beams made this way are Douglas fir. There may be a stronger wood, but I’m not aware of it. Today, lumber mills make beams like they make plywood. They use layers of solid wood that are glued together to make incredibly strong structural engineered timbers.

How far can a PSL beam span?

* The span and load tables in this guide cover beam spans up to 60 feet; however, 2.2E Parallam® PSL beams can be delivered in lengths up to 66 feet.

Can I rip a PSL?

No, Parallam® Plus PSL must maintain its original cross section and shall not be re-sawn in depth or thickness.

Do LVL beams sag?

Your wood/LVL will sag much more. What you are describing is ultra typical when there is a point load above and they used LVL. I don’t know why cities keep allowing the use of LVL for anything more than 10 feet. It will look great and then year 2-3 it starts sagging… year 4-5 you get cracks and notice it…

Is LVL stronger than wood?

Laminated veneer lumber (LVL) studs can provide ultimate strength against wind and shear-loads and can be up to two and a half times stronger than standard framing lumber of the same dimension in compression and tension, which means a wood-framed house can be designed and constructed to withstand 100 mph or more .

How much stronger is an LVL beam?

Laminated veneer lumber (LVL) studs can be two times stronger in compression and tension than standard framing lumber of the same dimension.

Article first time published on

How heavy is a PSL beam?

SeriesSeries Parallam®Product WidthProduct Width 7″WeightWeight 31 pounds per footBrandBrand Trus Joist®Product Type1Product Type1 Parallel Strand Lumber (PSL)

How much is an LVL beam?

TypePer Foot InstalledTotal Cost InstalledLVL Beam$50 – $200$800 – $2,500Steel I-Beam$100 – $400$1,200 – $4,200

Is glulam the same as LVL?

LVL refers to a manufactured timber product made from thin veneers (often 3mm) glued together to form large structural members, often known as Hyspan or similiar. Glulam is made from thicker sections of timber, generally 15-45mm thick, glued together to form a large variety of products.

How big of a LVL beam do I need?

Design a beam width based on the fact that the typical width of an LVL beam is 1 3/4 inches. The width can be increased by laminating in multiples of 1 3/4 inches. Beam width should be 1/4 to 1/3 beam depth.

Which beam is strongest?

There is no such thing as a “stronger beam” in engineering design. Whether the beam is steel, reinforced concrete, timber, or any other material, it can be sized to withstand whatever load is applied to it (up to a practical limit).

What is LVL timber?

Laminated Veneer Lumber (LVL) is a high-strength engineered wood product used primarily for structural applications. It is comparable in strength to solid timber, concrete and steel and is manufactured by bonding together rotary peeled or sliced thin wood veneers under heat and pressure.

Can LVL be ripped?

LVL is made in billets up to 48 inches wide that are ripped to commercially available standard depths. It’s okay to rip LVL beams to a smaller depth, too, though you’ll have to recalculate the beam capacity.

Can an LVL be cut?

Although they are a manufactured product, cutting an LVL is no different from cutting a regular piece of lumber. Measure from the end of the beam to the place you want to make your cut and mark it with the carpenter’s pencil. … Move the saw along the cut line until you have cut completely through the beam.

Can you notch a parallam?

Parallam® Plus PSL is permitted to have a notch or taper cut without voiding the 30-year warranty under the following conditions: Notches and taper cuts occur in above ground applications only (Use Category 3B for Structural Composite Lumber as defined by the American Wood Protection Association).

How far will an LVL span?

Due to its strength, an LVL beam can span up to 60 feet and is much stronger than traditional lumber. Generally, you can find LVL beams in 4-foot increments starting at 24 feet and going up to 44 feet long, with special orders up to 60 feet. LVL beam thickness is usually between 1 ¾ and 7 inches.

Can PSL beams get wet?

For beam or column applications exposed to weather or high moisture, a preservative treated product – such as Parallam® Plus PSL – may be an option. Properly store Weyerhaeuser OSB and EWP products such that they are protected from moisture.

How big of a beam do I need to span 20 feet?

Wood beam size for a 20 foot span:- as per general thumb rule, for a 20 foot span, size of wood beam or lumber joist should be 2×14 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 350mm (14″) and width of beam is 50 mm or 2″.

What are the disadvantages of LVL?

Although its dimensional stability is better than solid wood, the product may result in some defect, such as warping, if it is not properly stored in the warehouse. Also, LVL requires high capital investment to have relatively low production cost.

Is LVL lighter than wood?

They are made up of a vertical web of dense oriented strand board (OSB) in the middle, with a horizontal flange of dimensional lumber or LVL above and below. They’re used for joists and rafters, because they’re lighter than sawn lumber and able to span greater distances.

Are LVL beams stronger than lumber?

LVL offers several advantages over typical milled lumber: Made in a factory under controlled specifications, it is stronger, straighter, and more uniform. Due to its composite nature, it is much less likely than conventional lumber to warp, twist, bow, or shrink.

Can LVL beams fail?

It has been reported that it is very difficult to fail LVL in edgewise shear using a prismatic cross section due to the high shear-to-bending strength ratio of the LVL, as compared to other engineered wood products such as glulam [3,4].

Do LVL beams have a crown?

LVL beams are dead straight, which was a big advantage on this project compared to glulam beams that usually have a crown. The glulam crown wouldn’t typically be a problem, except that it could have put undue pressure on the middle of our second floor wall above, due to the installation below.

How far can a 2x10 LVL beam span without support?

A 2×10 beam – made up of two 2x10s nailed together – can span up to 11′ without support beneath a deck that is 4′ wide. For a more normal-sized deck, the same beam can span 8′, supporting a deck that is 8′ wide.

Can I drill holes in LVL beams?

Whenever possible, avoid drilling vertical holes through LVL beams unless the beam width is at least 3-1/2 inches. Prior to drilling any vertical holes, an engineer or architect qualified in wood design should be consulted.

What is the longest LVL beam?

LVL is available in lengths up to 24.4 m (80 ft), while more common lengths are 14.6 m (48 ft), 17 m (56 ft), 18.3 m (60 ft) and 20.1 m (66 ft). LVL can easily be cut to length at the jobsite.

How much stronger is LSL?

With short-span applications like window and door headers, it’s shear strength that counts. TimberStrand® LSL has a shear stress of 400 psi—up to 50% stronger than other common EWPs—making TimberStrand® LSL the right solution for the right job.
