A 20% lighter fiberglass mesh-reinforced cement backerboard for residential and commercial tile, stone, slate, and thin-brick applications.

What is WonderBoard made out of?

WonderBoard® Lite panels are composed of stable Portland cement, EPS beads, aggregates and reinforcement.

Is durock and WonderBoard the same thing?

I found that Wonderboard is stiffer than Durock (less floppy) which makes it easier to handle, carrying up stairs, loading etc. It also seemed to have a more consistent cement fill with less voids and less soft and “crumbly” areas than Durock.

What is the difference between Hardibacker and WonderBoard?

HardieBacker is made of a blend of cement, sand, and cellulose fibers, while WonderBoard is made of a cement mixture reinforced by mesh. This difference in materials affects their other properties. HardieBacker is lighter and easier to use than WonderBoard because it is not a pure cement backerboard.

What is WonderBoard?

Wonderboard: – a true cement board with a mesh facing for integrity. -brittle. Cut it into thin strips and the strips can easily break. -cutting, score the surface and cut the mesh reinforcement with a handheld carbide cutter and snap, or cut with a diamond blade.

Can WonderBoard get wet?

I spoke to a wonderboard marketing rep. who said the stuff can get wet for 30 years and not fail and that there is no styrofoam in it.

Is WonderBoard a cement board?

A 20% lighter fiberglass mesh-reinforced cement backerboard for residential and commercial tile, stone, slate, and thin-brick applications.

Can you use WonderBoard on shower walls?

Installing cement backerboard is one of the more popular choices for a shower wall substrate. Cement backerboards include Hardiebacker, Durock, Fiberboard, wonderboard, and similar products. These materials bridge the gap between expense and effectiveness.

What is similar to WonderBoard?

Types of cement backer board Permabase is National Gypsum’s product and it is very much like WonderBoard from Custom Building Products. Both of these boards are a cement and aggregate core with a fiberglass mesh “skin.” Durock from USG is a slightly lighter weight version of comparable construction methods.

What is the best backer board for a shower?

Cement board is a good, reliable backer board that works well on both floors and walls. Keep in mind that most tile setters err on the side of caution and brush a waterproofing membrane on top of cement board when it is in wet areas like showers or tub surrounds.

Article first time published on

How thick is WonderBoard?

When using 7/16″ WonderBoard Lite, base should be a minimum of 5/8″ thick. The total wood subfloor including the plywood and WonderBoard Lite should be a minimum of 1″ thick.

Is WonderBoard fire resistant?

Fire Performance: WonderBoard® has achieved a fire resistance rating for cementitious backer units per ANSI/UL 263 and CAN/ULC S101, Report No. 21766. Flexural Strength ASTM C-947 > 750 psi 900 psi (62.9 kg/cm sq.)

Can you put WonderBoard over drywall?

It should be fine. The wonderboard in this case is just acting as a backerboard for the tile. I wouldn’t put thinset between the sheetrock and cement board.

Does WonderBoard smell?

This stuff has an incredibly strong, noxious odor.

Can you nail into WonderBoard?

Lay the WonderBoard sheets onto the motar. Be sure to leave a 1/4-inch gap at the walls and a 1/8-inch gap between sheets. … In a pinch, you can also use 1 1/4-inch galvanized roofing nails.

Can WonderBoard be painted?

Do not paint a cement board unless you have thoroughly cleaned it first, or you may have problems with adhesion. … Unlike standard cement, which is not an ideal surface for paint adhesion, fibrous cement boards contain pores that soak in the adhesives within the paint, making the finish much more durable.

What is the difference between backer board and cement board?

Cement backer board is also called cement board, and it’s the most commonly used backer board for all manner of ceramic and porcelain tiles. Made of cement and reinforced on the top and bottom with fiberglass, this waterproof backer board is generally used for tiled shower surrounds and floors in wet areas.

Does water hurt cement board?

Cement board resists water damage but is itself not waterproof. It will actually absorb moisture, but it has excellent drying properties.

Can cement board be left exposed?

Most brands of concrete backer-board consist of a fibrous reinforcement cement composition molded into sheets. It is extremely hard and waterproof, meaning it will not deteriorate over time when exposed to water, making it ideal for use in high-traffic areas that are susceptible to the adverse effects of moisture.

Do I need to seal cement board before tiling?

Contrary to popular thought, tile and grout are not waterproof, and some moisture will penetrate even if sealant is used. … However, if you choose to use concrete backerboard, which is much stronger and more durable than gypsum board, a water vapor membrane must be placed underneath it or a sealant applied on top of it.

Is WonderBoard Lite good?

Overall, the 7/16″ WonderBoard® Lite is a much improved cement backerboard for the installation of ceramic and natural stone tile in wet areas. … For larger tiles, with one side greater than 15″, the handbook recommends a medium bed mortar that can range in thickness from 3/16″ – 3/4″.

How thick should cement board be for tile?

Floors: A 1/4-inch minimum thickness is needed, but thicker panels are also fine. Walls: Use 1/2-inch or 5/8-inch-thick cement board, not 1/4-inch. The extra thickness is needed when spanning the studs and it provides a solid base for the tile.

Can you use 1/4 cement board on floors?

Both 1/4- and1/2-inch cement board are appropriate for floors. To install cement board on floors, cement board manufacturers mandate a 5/8-inch plywood subfloor or OSB underlayment.

Do you need to tape Wonderboard?

For tile backer boards such as Durock, Wonderboard, Hardiebacker, Permabase, and others the seams between the board need to be treated with 2-inch alkali-resistant mesh tape. … It helps to make the walls that are to be tile more monolithic.

Can you just screw down backer board?

Screw and Joints Do not use drywall screws as they are not recommended to be used to hold the backer board in place. All of your backer board pieces should be cut before they are placed on​ the floor. … It is important to highlight that screws shall not be installed all the way down to the floor joists.

Can you reuse cement board?

Undamaged cement backer board does not need to be replaced. If tile has not been attached directly to the backer board, and it has not been dented or punctured, it can be reused without any special preparation.

Can you remove tile from cement board?

If you have a single or a few cracked tiles, they can be removed from the cement backerboard and replaced. The grout is dug out from around the tile with a utility knife first to help loosen the tile. The tile can be broken up with a hammer, or popped free with a putty knife.

Can you use WonderBoard on the floor?

WonderBoard Lite can be used in applications such as walls, ceilings, floors, decks, countertops and vanities. Use under any tile or natural stone. Not for use over concrete/gypsum substrates.

How do you waterproof WonderBoard?

1/2″ WonderBoard is unaffected by water but it is not waterproof. If the area behind the backerboard must be kept dry, a moisture barrier or waterproof membrane such as RedGard® Waterproofing and Crack Prevention Membrane must be used.

Which side of Wonderboard Lite faces out?

Should I install cementitious backerboard (Durock, Wonderboard, etc.) with the rough or the smooth side facing out? A. Backerboard is usually installed rough side out when used under a thin-set mortar for slate or ceramic tile flooring, and smooth side out when it is a base for adhesive-set wall tile.

Is thin set a mortar?

The word “thinset” is sometimes used interchangeably with “mortar,” because it’s a type of modified mortar made specifically for tile. Thinset is made of sand, water, and cement, and can also contain additives for increased bonding, water resistance, and flexibility.
