There are four basic sizes of plastic waste pipe for different plumbing uses. The hand basin waste pipe is 32mm. 40mm is for sink and bath waste pipe.

Is a bath waste pipe a standard size?

Plastic waste pipe is available in 4 basic sizes (external diameter) for different plumbing uses: … 40mm – for sink and bath waste pipe. 110mm – for soil pipe and main drains.

What size is bath drain pipe?

Down the Drain According to Bonnets Stems and Accessories, Inc., a standard modern bathtub drain is 1 1/2 inches in diameter – the width straight across the middle. Rough-in plumbing should be calculated for a 1 1/2-inch pipe.

What size is UK bath waste pipe?

Common Waste Pipe Sizes in the UK 40mm – Used under kitchen sinks and also bathroom showers/baths. 50mm – Less popular and usually found in commercial buildings, occasionally seen in larger residential dwellings.

What size is standard waste pipe?

Advertised DimensionPush Fit DiameterSolvent Weld Diameter32mm34mm36mm (1 1/4″)40mm41mm43mm (1 1/2″)50mm54mm56mm (2″)110mm110mm110mm

What size are UK water pipes?

In UK domestic plumbing the sizes commonly found are 8mm, 10mm, 15mm, 22mm, 28mm, 32mm, 40mm, 50mm, 68mm and 110mm; with sizes up to 28mm being used for hot and cold water supply, heating and gas supply, and larger sizes for waste, rainwater, soil and ventilation.

Are all toilet waste pipes the same size?

Waste drain pipes for toilets in modern plumbing systems are either 3 inches or 4 inches in diameter. The wider the pipe, the more waste it can move and the less likely it will be to clog. A 4-inch pipe can carry about twice the waste of a 3-inch pipe.

What are the different sizes of plumbing pipes?

Looking at copper first of all, there are metric and imperial sizes. Metric sizes are measured using the outside diameter, i.e. the outside diameter is either 8mm, 10mm, 12mm, 15mm, 22mm, 28mm, 35mm, 42mm and so on.

What size is push fit waste pipe?

Our Push Fit Waste is available in White (32mm & 40mm), Grey (32mm, 40mm & 50mm) and Black (32mm & 40mm).

How are pipe sizes measured UK?

Find the outside diameter of your pipe to the nearest millimetre, use a tape measure or vernier gauge. Then find this size down the left hand column, read across the four coloured columns on the right to find the group and description for your size pipe.

Article first time published on

Can you use 32mm waste for a shower?

yes.. I will be using 40mm all the way to where the 32mm disappears through the joists and down into the stack. Only other option to access the stack is to remove a stud wall and re-build afterwards.

What size is bathroom sink waste?

Sometimes people get confused and ask why is there 2 sizes of basin wastes? the simple answer is that they are 1¼” BSP (32mm) and bath/sink wastes are 1½” BSP (40mm).

Can you use 32mm waste for a bath?

Use the 32mm if it gets you out of a problem, bath will take longer to empty thats all.

Can a toilet and shower share the same drain?

In the US, with modern regulations, in most municipalities, yes, they do. The water and solids from your toilet waste line and the water from your drains end up in the same sewer line, if you have access to a municipal sewer system.

What size should water pipes be?

In most cases, the main pipeline from the street to your home is either 3/4 or 1 inch in diameter, supply branches use 3/4-inch-diameter pipe, and pipes for individual components are 1/2 inch. Remember that water pressure decreases by a half-pound per square inch for every foot pipes extend above your water supply.

Is 15mm the same as 1 2 inch?

1/2″ pipe refers to the internal diameter, 15mm pipe is the external diameter… In my experience they are so similar that you can even use solder fittings without a worry, so using 15mm olives on 12″ pipe isn’t a problem.

What is the inside diameter of 40mm waste pipe?

The internal and external diameter of “40mm” pipe varies according to material, fitting type etc. FloPlast solvent pipe has an internal diameter of 1.5” (38mm) and an external diameter of about 43mm.

What diameter is caravan waste pipe?

Caravan waste pipe for use on internal / external plumbing and also great when pitching on a fully serviced pitch. Available in 20mm, 23.5mm & 28.5mm measured by the inside diameter. This waste pipe is commonly used in Motorhomes, Caravans & Campers.

What size sewer pipe do I need?

A standard rule of thumb is that sewer pipes leading away from a toilet are 3 inches in diameter. Sewer drains from laundry sinks or washing machines are 2 inches in diameter and those from sinks in the kitchen, bathroom or powder room generally use a 1.5-inch pipe.

Is waste pipe measured internally or externally?

Drainage Pipe is measured externally. 110mm is the external diameter of our 110mm Floplast underground drainage pipe. Drainage Pipe is also available with an integral socket on one end, the dimensions of this socket are shown below on the right.

What is 32mm waste pipe used for?

32mm is generally used for hand basins and low volume outlets and 40mm used for showers, baths and sinks.

What size waste should a shower have?

A shower waste would normally be in 40mm pipework, but quite what you’ve got hidden from view is anyone’s guess. Badly installed pipework can be the cause of blockages, an inspection of the installation would be the only way.

How far can you run 32mm waste pipe?

The limits can be very restrictive and are as little as 1.7m for a 32mm waste pipe to a wash hand basin. By increasing the size of the pipe, you can place the fitting further away – typically between 3 and 4m away for a 50mm pipe.

What size are sink waste?

Generally, the following types of appliances use a standard size waste trap and waste pipework: Wash hand basins: 32mm (1 ¼ inch). Sinks: 38mm (1 ½ inch). Urinals: 38mm (1 ½ inch), or 50mm (2 inch).

Are all shower wastes the same size?

Shower traps use 40mm usually or 50mm waste pipe if shower has a high flow rate,plus if it’s a long run. Look at McAlpine Shower traps,quailty item,they are available in various depths & have various water seal 50mm,80mm,etc, all depending on the shower tray used.

Can I connect sink waste to shower waste?

Do not use combined sink and shower waste. When the sink plug is pulled, the water will rise up into the shower tray. Hi Plumbbob, Thanks for your reply.

How far from the wall should a toilet waste pipe be?

1 Answer from a MyBuilder Plumber Close coupled toilets/ back to wall toilet pans/ or vanity unit toilets. All of which have different distances but the height will always be the same which is 7 inch from finished floor tho center of toilet outlet.

How long after installation can a toilet be used?

It can be used as soon as the water supply is turned on. Toilets are bolted to the floor flange, so there is nothing to dry or cure. About 30 seconds after the water is turned in. The time it takes to fill the tank.

Can two toilets share the same drain?

In answer to the question, yes, two toilets can share the same drain line but not the same drain hole.
