Generally, most VERSA-LOK units need geogrid for walls taller than three to four feet. If there are steep slopes near the wall, loading above the wall, tiered walls or poor soils, then even shorter walls may need geogrid.

How tall can a retaining wall be without geogrid?

HOW HIGH CAN WALLS BE BUILT WITHOUT THE USE OF GEO-GRID? The various Keystone retaining wall systems can be constructed between two-feet and three-feet high (in ideal conditions) depending on the type of unit, soil conditions, site geometry, amount of batter used and surcharge on top of wall.

How deep should geogrid be?

STEP 2 | Excavating The Geogrid Retaining Wall Typical retaining wall burial depth or embedment Depth is 6″ to 12″ (15 to 30cm) Or 10% of the total height of the wall. Follow engineers cross section details or design parameters to ensure the correct embedment depth is being followed.

Why do you use geogrid?

Geogrid is a geosynthetic material used to reinforce soils and similar materials. Geogrids are commonly used to reinforce retaining walls, sub-bases or sub soils below roads or structures. Soils pull apart under tension. Compared to soil, geogrids are stronger in tension.

Do I need geogrid for 3 foot retaining wall?

Wall Heights that Require Geogrid Soil Reinforcement Generally, most VERSA-LOK units need geogrid for walls taller than three to four feet. If there are steep slopes near the wall, loading above the wall, tiered walls or poor soils, then even shorter walls may need geogrid.

How much does geogrid cost?

Number of UnitsPrice Per Unit1+$1,148.082+$826.083+$729.0010+$630.01

What can I use instead of geogrid?

As such, woven slit-film geotextiles are stronger and can offer a highly efficient and cost-effective alternative to rigid, punched-and-drawn polypropylene geogrids. In addition to superior strength and lower cost, slit-film geotextiles offer an added advantage over any geogrid: separation.

How much geogrid do I need for a retaining wall?

When a Retaining Wall Needs Reinforcement To determine the number of rolls needed, multiply the length of your wall (in feet) by the number of layers needed, and then divide by 50 (the length of a roll of AB Reinforcement Geogrid).

How do geogrids work?

Geogrid is a flexible mesh that is used to create a reinforced coherent mass behind the retaining wall by stabilizing the soil. The stability of the soil depends greatly on the friction angle it contains. … In soil, the friction angle is the maximum shear force between particles of soil as they try to pass each other.

Do I need geogrid for retaining wall?

For most 6″ or 8″ wide split-face limestone retaining walls, geogrid will be something to consider when the exposed wall height exceeds 24″. … Once the retaining wall is over 6′ in height, if it isn’t being built from 24″+ wide limestone outcroppings or similarly sized, dense material, geogrid is required.

Article first time published on

Can you overlap geogrid?

Never overlap geogrid layers without soil in between the layers; always provide at least three inches of soil fill between overlapping geogrid layers. Slick surfaces of the grid will not hold in place properly when placed directly on top of each other.

Can you cut geogrid?

Measure and cut geogrid to the specified length. Geogrid may be cut using a razor knife, scissors, sharp knife or other cutting tool. Care should be taken to avoid injury while cutting the geogrid.

What is the difference between geogrid and geotextile?

Differences Between Geogrids and Geotextiles Geotextiles are manufactured for separation, filtration, and drainage purposes, whereas geogrids are specifically manufactured as a reinforcement material. … However, the geotextile can allow the free movement of water from the soil into the aggregate layer, and vice versa.

What is biaxial geogrid?

Biaxial geogrid is a type of geogrids. It is made from high polymer. Biaxial geogrid has high strength in both longitudinal and transverse direction. It is made through the process of extruding, sheet forming, punching and stretching. Biaxial geogrid has good bearing capacity.

What does MSE wall stand for?

A Mechanically Stabilized Earth (MSE) retaining wall is a composite structure consisting of alternating layers of compacted backfill and soil reinforcement elements, fixed to a wall facing.

How does retaining wall drainage work?

Retaining wall drainage is critical. It ensures water does not collect behind the wall, causing it to fail. A quality drainage system collects and redirects rainwater away from the wall. It decreases pressure on the soil around the foundation and within the wall itself, reducing erosion and settlement.

Do you put fabric behind retaining wall?

Landscape fabric is thin and sturdy and is a simple way to preserve a retaining wall’s construction. Dig a 6- to 8-inch wide trench immediately behind the retaining wall with a shovel. Dig slowly and carefully to avoid putting added pressure on the wall and causing it to topple over.

How do you make geogrid?

Geogrids are commonly made of polymer materials, such as polyester, polyvinyl alcohol, polyethylene or polypropylene. They may be woven or knitted from yarns, heat-welded from strips of material, or produced by punching a regular pattern of holes in sheets of material, then stretched into a grid.

How wide is geogrid?

Generally, Geogrids are 3.65 m wide and the length is depending on design requirements. Ultimate strength of geogrids is determined by test as per either ASTM or Geosynthetic Research Institute (GRI).

What is geosynthetics engineering?

Geosynthetics are synthetic products used to stabilize terrain. They are generally polymeric products used to solve civil engineering problems. This includes eight main product categories: geotextiles, geogrids, geonets, geomembranes, geosynthetic clay liners, geofoam, geocells and geocomposites.

How is geogrids used as a soil reinforcement?

Reinforcement geogrid is used to reinforce soil for steepened slopes and retaining walls. … To be effective, reinforcement grid must be able to maintain the tensile reinforcement load and efficiently transfer that tensile load into the surrounding soil.

What is geogrid mesh?

Geogrids are geosynthetic material made from polypropylene, polyethylene or polyester. They are used in several civil engineering related applications to provide ground reinforcement. … Geogrids work by interlocking with the granular or soil material placed over them.

How do you reinforce a retaining wall?

The wall can be strengthened by transferring some of the shear force to the base where the wall meets the ground. This can be done by either extending the footing of the base or placing concrete to thicken the base. Installing anchors or tiebacks is another option for extra strength.

How do you backfill a retaining wall?

1. Lay your base of compacted native soil (about three inches deep).
2. Tamp the soil to ensure that it is secure and firm.
3. Fill the next six to twelve inches with aggregate or gravel.
4. Tamp the gravel or aggregate to ensure a sturdy base.

How do you reinforce dirt?

Soil reinforcement is performed by placing tensile elements in the soil to enhance its natural stability and strength. This is achieved by bringing reinforcement elements in contact with surfaces in the aggregate and sub-base of soil mass.

How do you fix a block retaining wall?

DO start with a good foundation. Your retaining wall will only be as strong its support system. For a stacked-block retaining wall that’s no higher than four feet, a trench filled with three inches of crushed rock will help keep the wall from shifting and settling.

What is gabion retaining wall?

A gabion wall is a retaining wall made of stacked stone-filled gabions tied together with wire. Gabion walls are usually battered (angled back towards the slope), or stepped back with the slope, rather than stacked vertically. … Galvanized steel wire is most common, but PVC-coated and stainless steel wire are also used.

What blocks are best for retaining wall?

Concrete blocks are ideal for building walls to hold back the soil after you dig into a slope for a pathway, patio, or another landscaping project.

What is a surcharge for a retaining wall?

Any added weight above a retaining wall is called a surcharge. Patios, swimming pools and driveways are common residential surcharges. Your wall may need additional support if a surcharge is present.

What is an Allan Block wall?

Allan Block Products Concrete block retaining wall system good for any residential or commerical application. Multiple sizes, shapes, textures and colors available. Retaining Walls.

What is a gravity retaining wall?

Gravity Retaining Walls A retaining wall that relies solely on it’s own weight to stand up is called a gravity wall. Allan Block combines the basic engineering principles of setback, leverage and total unit mass with simple mechanics to make highly stable gravity walls.
