Type MC cables are widely used in 600 volt and MV power, lighting and fixture whip control applications. They are permitted for use on services, feeders and branch circuits for power, lighting, control and signaling circuits in accordance with Article 330 and 725 of the NEC.

What type of wiring is used in commercial buildings?

Metal-clad cable (type MC) per NEC 330 is one of the more commonly used cable types in commercial construction. MC cable is a set of conductors assembled within a metallic sheath of either steel or aluminum interlocking armor where the sheath is not used as a ground path.

Can you use NM cable in a commercial building?

NM cables are permitted to be installed in a Type V commercial building (for example), only if it is concealed in a stud/ceiling space (or any other space) with min 1/2″ sheetrock or other finish material with equivalent 15-minute fire rating.

Is MC cable allowed to be exposed?

Section 330.15 states: Exposed runs of cable, except as provided in 300.11(A), shall closely follow the surface of the building finish or running boards. Exposed runs shall also be permitted to be installed on the underside of joists where supported at each joist and located so as not to be subject to physical damage.

Can you run MC in concrete?

Can I install Type MC in concrete or against concrete or mortar? A. Yes, if the cable is listed for the application. Type MC cable is available with an outer PVC jacket and is permitted to be installed in parking decks, concrete pours and for direct earth burial if it is identified for such use.

Which type of cable does not required building?

PVC cable does not require bedding. Q.

Is MC cable and armored cable?

MC cable is easier to remember because it’s an abbreviation for “metal clad” or “metallic-sheathed cable.” … Both are essentially just names for armored cable. When fiber is armored, it has a conductive jacket because the material is made from metal, usually aluminum or steel.

Can you use electrical PVC in commercial buildings?

Exposed — PVC conduit is permitted to be used for exposed work. … Schedule 40 PVC conduit is permitted for exposed locations where not subject to physical damage. Schedule 80 PVC conduit is identified for use in areas subject to physical damage.

What type of wire is run in commercial but not residential?

Commercial wiring has what is called a TTHT coating. TTHT is a thermoplastic, high-heat resistant, nylon coating that is much tougher than the wiring in your home. Because of the liability involved in commercial applications the wiring has to be tougher.

Does MC cable need to be protected?

According to NEC Article 330.30, MC cable must be supported and secured at intervals of 6 feet or less (unless routed through a framing member) and cables containing four or fewer conductors sized no larger than 10 AWG must be secured within 12 inches of every termination.

Article first time published on

Can you use MC cable underground?

The Metal Clad Cable includes a grounding wire and can be used in outdoor applications. It can go into concealed and unconcealed spaces, and even buried underground. The National Electric Code (NEC), it is also approves it for difficult locations that involve exposure to moisture and hazardous elements.

Can I run MC cable through drywall?

Armored cable is fine in drywall – indeed, it’s superior to NM cable, and required in many/most commercial occupancies if not using conduit.

Why is Romex illegal?

Staffers there said house wiring known by the brand name Romex can be dangerous if the insulation is gnawed by rodents or punctured by nails. They said the flexible insulation on the cable lacks the protection of conduit, the rigid metal tubes that encase wires.

Is NM cable allowed in high rise buildings?

The 2002 National Electrical Code (NEC) is permitting the use of Nonmetallic Sheathed (NM) cables to be installed in buildings (structures) with heights higher than three stories. … The majority of jurisdictions in the United States use a version of the National Electrical Code (NEC).

Can you run Romex in a metal building?

Romex can be used in a metal building as long as the cable is protected through the holes in the studs with bushings. You should be careful to meet the support requirements in vertical strokes and boxes.

Can you use MC cable outdoors?

These cables can be installed either indoors or outdoors and in exposed and concealed locations. They can be direct buried, where identified for such use. … Type MC cable with a nonmetallic jacket can also be used in a wet location.

Can you pull MC cable in conduit?

Although the Hazardous Locations section of NEC Chapter 5 requires threaded rigid conduit (RMC) or threaded steel intermediate conduit (IMC) for the real hardcore hazardous (classified) locations, MC cable is allowed in some installations with some listing restrictions.

Can MC cable be used in damp locations?

General use MC cables cannot be used in wet locations but there are some types of specialty MC cables that can. The most common is the PVC coated, sunlight resistant, direct burial listed MC cable in the image.

What type of wire is in MC cable?

MC cable contains conductors from 18 AWG through 2000 kcmil for copper and 12 AWG through 2000 kcmil for aluminum. Typical branch circuit Type MC cables have copper conductors with THHN, THHN/THWN or XHHW insulation and are suitable for circuits up to 600 volts.

Is MC safer than Romex?

Safety: Compared to Romex, MC cable is safer to install due to its metallic sheath. This sheath helps protect against accidental shearing and penetration, reducing the risk for accidental wire exposure. Romex sheathing is easily penetrated or sheared, making it less safe unless run through protective conduit.

What are the three types of cables?

Fiber optic cable, twisted pair cable, and coaxial cable are the three main types of network cables used in communication systems.

Which type of wiring is used in residential building?

Non-metallic sheathed cables, sometimes called Romex or NM cables, are flexible electrical cables that are widely used in residential setups. The basic model of these cables comes with two insulated wires including a ground copper wire to provide a safe flow of electrical current in case something goes awry.

What are 5 types of wires and 5 types of cables?

• Communications Cable. Coaxial Cable. …
• Direct-Buried Cable (DBC)
• Non-Metallic Sheathed Cable (NM, NM-B)
• Metallic Sheathed Cable (Armored Cable, AC or BX, MC) Armored Cable (AC) …
• Multi-Conductor or Multicore Cable:
• Paired Cable.
• Portable or Extension Cord.
• Ribbon Cable.

What is MC cable?

MC Cable Definition MC Cable, by most common definition, is a factory assembly of one or more insulated circuit conductors enclosed in an armor of interlocking metal tape or a smooth or corrugated metal sheath.

What is the difference between residential and commercial wiring?

Residential wiring refers to any electrical work or wiring that’s meant for residential buildings and houses. This type of wiring is confined to homeowners. On the other hand, commercial wiring is incredibly complicated and is designed for commercial buildings such as warehouses, hospitals, and malls.

What is the difference between commercial building wiring and residential building wiring?

From a technical aspect, most residential wiring are single phase and 120 Volts, consisting of three wires, positive, negative, and neutral. … Commercial wiring often has a higher level of insulation, known as TTHT (Thermoplastic, high-heat resistant, nylon coated).

Can you run PVC conduit in a commercial building?

Conduit. A common method of electrical wiring in a commercial setting is by use of conduit. … For underground conduit runs or conduit embedded in concrete slabs, PVC conduit is used, as it will not rust or corrode. PVC conduit can also be found in areas where moisture, water, or chemicals may be present.

What is commercial electrical wiring?

Commercial electrical wiring generally uses three-phase power instead of single-phase power. In simple terms, this means cables have four or five wires instead of only two. This consists of three live cables, a neutral cable and an earth cable.

Can you use PVC conduit in a garage?

Combining metal boxes and PVC conduit is fine, but unlike an all-metal system, PVC requires you to run a separate ground wire and bond it to each metal box or light fixture with either a screw or a special grounding clip.

Can MC cable be painted?

The quick answer is “yes,” but let’s cover some of what you’ll need to know first. Painting the armor does not violate the National Electric Code (NEC), however, this process can be time consuming and also create more cleanup on the job-site utilizing pre-painted armor saves time and labor.

Can MC cable be used with plastic boxes?

MC Cable Is for Metal Boxes Only! Plastic or fiberglass electrical boxes aren’t designed to be used with MC cable. Even if you’re able to rig up a connection to a plastic box, you will fail the electrical inspection.
