Zone valves are responsible for reducing energy wastage, they ensure that hot water and therefore heat is there as and when you need it, however, they also ensure that when you don’t need it, energy is not wasted on heating a system that is not in use.

How do I know if my zone valve is working?

To test if your zone valve is working, switch off demand for your hot water (you can do this via the timer – set Hot Water to Off). Now create demand for central heating – turn up the thermostat and make sure the timer is set to ‘On’ or ‘Continious’.

How much does it cost to replace a heating zone valve?

Zone valves cost $60 to $200 for most residential systems. You’ll need one for each zone. They control the flow of water or steam to each area of your home.

Where is the zone valve located?

Location of Zone Valves A zone valve can be located right after the boiler and circulator (hot side), or at the end of the zone circuit (cold side). If able, it is recommended to locate the valve on the cold side as it will be less damaging to the valve and improve its life-time.

What happens when a zone valve fails?

If power to the valve fails, it can be opened manually, allowing some circulation by gravity (Figure 4). The valve automatically returns to normal operation when power is restored. The manual-open position is recommended during soldering to keep from overheating the ball plug.

Why is one zone of my heat not working?

Sometimes, a heating zone will not work properly because water cannot move through the baseboard radiators. This happens when an air bubble blocks the pipes. To help draw out air, locate the bleeder valves on all the radiators in the affected heating zone. … Close the valves when water starts to come out of the openings.

How long does a zone valve last?

They each lasted about 10 years in use.

How do central heating zone valves work?

Explanation of Zone Valves on Heating Boilers – Controlling Hot Water Heat. … In all cases, when the zone valve is fully open, an “end switch” inside the valve tells the heating system’s circulator to begin operating, causing hot water to flow through the zone.

What does a zone valve do in central heating?

A zone valve is a specific type of valve used to control the flow of water or steam in a hydronic heating or cooling system. In the interest of improving efficiency and occupant comfort, such systems are commonly divided up into multiple zones.

Do I need to drain system to change Motorised valve?

Nowadays, most actuators can be replaced without needing to drain down the system. On older types, this isn’t possible and you will need to drain before starting work. Switch off the boiler then the electricity supply to it by removing the fuse from the plug or fused spur outlet.

Article first time published on

How do I know if my diverter valve is faulty?

A diverter valve may be faulty if the hot water taps still work while the radiators do not turn on. Another sign of a faulty diverter valve is if you only can only get lukewarm water from your taps.

How long do boilers typically last?

When properly installed and maintained, homeowners can roughly expect a conventional cast iron water boiler to last 20 or more years. There are plenty of examples of cast iron boilers lasting more than 50 years, but this is far from typical. Cast iron steam boilers may have a shorter lifespan.

Do zone valves fail open or closed?

In a hydronic (hot water) heating system electronically operated valves control whether hot water runs through a particular zone of the building, or not. It seems to be a common setup for the valve to ‘default’ to being CLOSED to flow, and only open when commanded to do so via a thermostat signal.

Why do zone valves go bad?

Zone valve problems come with the convenience of zone heating. … Sometimes the zone valve will fail to operate properly. This can be caused by a malfunctioning part on the valve itself or by a faulty thermostat or a faulty connection between the two.

Why is my heating working upstairs but not downstairs?

Because heat rises this warm area is likely to be the radiators upstairs in a house, or if you live in a flat it would most likely to be the radiator/s nearest the boiler or hot water tank. … If your radiators are hot upstairs and cold downstairs it is most likely that your pump is not working correctly.

What is zone control valve?

Zone Control Valve is a system designed to separate the area in case of maintenance and to get the indication of fire zone on a combination of Butterfly valve, Flow Switch, Pressure Gauge and Test & Drain Valves.

Can one thermostat control two zones?

Most simple thermostats, however, treat the entire home as a single heating zone. … With a smart thermostat for multiple zones, you can set up multiple different zones around your house. Following that, you can use your smartphone app or remote control to set different temperatures for all different rooms.

Should zone valves return or supply?

Install zone valves on the supply side of zone circuits to block upward gravity flow. Install a swing check valve on the return side of each zone to block the return side. The latter is necessary because buoyancy forces try to establish two-way flow in the return pipe.

What causes irrigation valve to stay open?

Air Trapped in the Valve: The valves may have air trapped in them. A small bubble of air becomes trapped in the tiny water ports of the valve, this stops the water from flowing through the port. Since the water flowing through the port is what holds the valve diaphragm closed, the valve stays open.

Why do my radiators only work upstairs?

Radiators Are Hot Downstairs but Cold Upstairs Cause: This could be caused by a blockage in the ball valve, or if there is a lack of water in the feed or expansion cistern. Quick Fix: Check the ball valve and expansion cistern for blockages, and bleed the radiator to remove any air that could be causing issues.

What is the major cause of thermostat and Zoning failure?

Thermostats that go wrong – Thermostats can go wrong, resulting in zones being heated and cooled at the wrong time of day or to the wrong temperature. … Problems in the wiring between thermostats can cause this to stop working properly. Damaged dampers – Dampers control the airflow in systems with ducts.

How does Honeywell zone valve work?

The Honeywell motor energizes and the zone valve rotates to the mechanical stop (in the open position). The motor remains energized until the thermostat (call for heat) opens and de-energizes the Honeywell motor. The spring return moves the valve to the closed position.

How do you drain a zone on a boiler?

The drain will be near the bottom of the boiler, connected to a pipe or to the boiler itself. Connect a garden hose to the boiler drain and run the hose to a floor drain. Turn on the boiler drain by turning the knob counterclockwise. Watch for water to begin to gurgle out of the hose.

What is the difference between a 2 port and 3 port valve?

The 2 port MTV normally closed models have end switches for electrical control of pump and/or boiler. The 3 port midposition valve has been designed to control the flow of water in domestic central heating systems, where both radiator and hot water cylinder circuits are pumped.

How does a 3 way motorised valve work?

This type of three way motorised valve has port A normally closed with no power to the valve. In this state, water can flow from port AB to port B. When the electrical supply is activated, the actuator motor overcomes the force of the internal spring and closes port B. This allows water to flow from port AB to port A.
