Most car manufacturers use a series of resistors to make the heater blower motor run at different speeds. And when one or more of these resistors burn out, you’re usually left with only one heater blower motor speed—high. The resistor module is easy and inexpensive to replace.

Why does my fan only work on high speed?

When a blower resistor fails, the highest fan speed usually is the only one that still works because it essentially bypasses the resistor and receives the maximum amount of voltage. When the resistor is working, it reduces the amount of voltage going to the lower fan speeds, so the fan runs slower.

How much does it cost to replace a blower motor resistor?

The average cost to replace the blower motor resistor at a repair shop is between $44 and $55 in parts and $70 in labor costs, for a total cost of around $114 to $125.

How do you know if a fan resistor is bad?

The most common symptom of a bad blower motor resistor is the blower motor will only work at one or two speeds. It can also cause the blower motor to stop working completely and you will notice no air coming from the vents.

How do I know if my blower motor relay is bad?

If you have a faulty blower motor, you may experience low airflow from the vents, even when the fan is on high. There will be no air coming from the vents if your fan isn’t working due to a bad blower motor resistor. Blown relay circuit fuses or melted relays are more serious signs of a bad blower motor relay.

Why wont my ceiling fan go high speed?

Ceiling fans that operate at speeds slower than normal can have one of four problems. Two of these issues are mechanical: loss of bearing lubrication and poor blade balance. The other two are electrical: either a bad capacitor or damaged winding.

Why won't my ceiling fan go on high?

It might be caused by the loss of lubrication, poor blade balance, bad capacitor, and loose screws. … You need to check the instruction manual for the lubrication. The oil reservoir of a ceiling fan needs to be filled with oil. Before refilling, you will have to clean the reservoir.

How do you test a fan resistor?

Place one lead of the Ohmmeter on terminal 1 of the resistor. Place the other lead on terminal 2 and check against specifications. If this circuit is open, showing infinity on the Ohmmeter, the blower resistor must be replaced. Move the lead from terminal 2 to terminal 3 and check this reading against specifications.

How do I know if I need a blower motor or a resistor?

Typically, if the fan will work on some speeds but not on others, the resistor is suspect. Okay, let’s say there’s no melting going on, but your fan doesn’t work on all speeds. Typically, if the fan will work on some speeds but not on others, the resistor is suspect.

What does a resistor do on a cooling fan?

The purpose of the cooling fan resistor is to remove heat from the engine’s coolant and from the A/C refrigerant. The resistor does this by drawing air through the radiator and air conditioning condenser.

Article first time published on

Where is the blower resistor located?

It’s located inside the dash, often on the opposite side of the steering wheel or inside the engine compartment on the firewall. A blower motor resistor or a blower motor control module is the part that controls the speed of the blower motor.

What is blower resistor?

The blower motor resistor is responsible for controlling the blower motor speed. In the past, this was done by varying the voltage supplied to the blower motor. … The change in resistance controls the current through the blower motor, which in turn limits the speed that the blower motor spins at.

Why does my fan in my car only work sometimes?

When a resistor fails, the fan will often run only at higher speeds or the highest speed, no matter what fan speed is selected. … If little air is coming through the vents (hot or cold), then it could be because the blower motor for the fan or a switch or resistor that controls fan speed isn’t working.

Why will a blower run on the on position and not on auto?

Other Blower Fan Won’t Run Problems The fan will run and blow warm air but only in FAN or FAN ON mode – delivering heat – but NOT in AUTO mode. This is a bad temperature sensor in the unit; replace the fan limit controller.

Can AutoZone test relays?

When it’s time to swap out your faulty relays, AutoZone has the solution to upgrade your vehicle without breaking the bank. … After conducting a simple electrical test, you can indicate if you need to replace an ignition relay.

How can you tell if a ceiling fan capacitor is bad?

The capacitor is usually a black box inside the switch housing of the fan. If the case appears burnt or melted in any way, that is also the sign of a bad capacitor and it should be replaced. Keep in mind that there may be other components in the circuit with the defective capacitor.

Can a ceiling fan cause a fire?

Wobbly & Shaky Ceiling Fans – Yes, a ceiling fan can cause a fire if it’s allowed to run at a high setting while shaking in its mount. If your fan isn’t secure, it could come loose and expose electrical wiring. Ceiling fans can quickly become a fire hazard if left unsecured.

What happens when a ceiling fan capacitor goes bad?

If the capacitor is bad, the fan is still getting power, but because the start coil is compromised, it can’t develop enough torque to start the fan. You can start the fan yourself, however, by giving it a push, and it will keep running. … A bad capacitor can also make the fan function erratically.

Why do fans slow down over time?

The capacitor on an electric fan is called a run capacitor, as opposed to a start capacitor that gives the needed extra torque for some motors to start. … When the capacitor burns out, the electric current through the coil is too steady to generate torque, and the fan slows down and stops.

Can a bad blower motor resistor cause no AC?

Power to the blower motor is fed through the blower motor resistor, so if it fails or has any issues power can be cut off to the motor. A blower motor without power will not be able to produce any air pressure, and as a result the heating and air conditioning system will be left with no air coming from the vents.

Is a switch a resistor?

We can think of the switch as a resistor of either 0 or infinity resistance, so it too can be labeled with a current arrow and a voltage polarity.

Does the coolant temp sensor control the fan?

On most modern cars, the cooling fan is controlled by the Engine Control Unit (ECU) which gets a signal from the coolant temperature sensor. If it’s not working, the fan won’t turn on when it needs to, which means the engine might overheat.

Is there a fuse for the blower motor?

Many vehicles have two fuses for the blower motor, one in the interior fuse block and the other under the hood. The blower motor is usually under the dashboard on the passenger side.

How do I know if my climate control module is bad?

Electronics failures within the module may have more unpredictable results. In some cases, your climate control may stop responding to your temperature settings or otherwise behave erratically. Odd, seemingly random behavior of the system typically points to an electronic issue.

What is a resistor block?

The Resistor Block is a two-circuit block with a resistor between the upper and lower circuits. The Voltage Indicator Block provides visual voltage indication across upper and lower terminals. The Component Block is a two-circuit block with a component between the upper and lower circuits.

Does a blower motor resistor have a fuse?

A fuse is often located on the resistor board. The fuse only protects the low and medium blower speeds. High speed will still work if the resistor fuse is blown.

Can you fix a resistor?

Resistors are easy to find if they have become defective because they can be measured with the electronic device turned off. Once a resistor is found to be defective, replacing it can return the electronic device to correct operation.

What are the symptoms of a bad thermostat?

• #1 – Temperature Gauge Reading Higher (or Lower) Than Normal.
• #2 – Sudden Air Temperature Changes Inside Vehicle.
• #3 – Coolant Leaking.
• #4 – Rumbling Noises.
• #5 – Heater Malfunction.

Can low coolant cause fan to not work?

What causes the radiator to stop working? The most common reasons a radiator fan is not working are luckily due to a blown fuse, bad relay, or a broken wire. It can also be caused by a faulty coolant temp sensor, low coolant level or the fan itself can be damaged.

Why does my air conditioner in my car work sometimes and not others?

Intermittent cooling is often caused by the components of your vehicle’s AC system freezing up. Typically an iced over evaporator is the culprit. … There may be numerous issues causing the icing—from a dirty cabin air filter to a blocked evaporator drain or an overcharged system.
