An electrostatic discharge test is a test to evaluate the durability of electronic devices when electrostatic discharge occurs when a person touches them. In winter, when you touch a doorknob or try to get out of a car, you may feel a “buzz” of static electricity discharge.

How is ESD testing performed?

The testing conducted consists of applying one positive and one negative pulse to the component, allowing a 0.3 second interval between pulses. A set of devices is exposed to these pulses at a given voltage level and pin grounding combinations; the device is tested for full static and dynamic parameters.

Why ESD test is done?

ESD testing is an electromagnetic compatibility test (EMC test). ESD testing simulates various electrostatic impacts that equipment might experience either during transit or operation. An electrostatic discharge test determines whether a product is in compliance with its ESD protective area and procedures.

What is ESD and why is it important?

Protecting electronic devices and components that are sensitive to electrostatic discharge (ESD) is very important in manufacturing processes or environments. ESD control products are needed in order to prevent damage from the electrical charges that accumulate during critical manufacturing processes.

What do ESD stands for?

ESD stands for electrostatic discharge. Under certain conditions, transference of electrical potential may occur when two materials with different charges come into proximity to each other.

What is EFT test?

EFT testing is an immunity standard used to test how electrical and electronic equipment operate under interference. EFT testing involves several tests to check the compatibility of a device with fast transients such as power line transients and electrostatic discharge.

What is EMC and ESD testing?

ESD stands for electrostatic discharge. Every EMC compliant product has to be tested on ESD during its development. This means that EMC compliant products should withstand certain electrostatic discharges of e.g. 1kV, 15kV or more.

What are the two types of damage that can be caused by ESD?

Static electricity, also known as electrostatic discharge (ESD), is an electrical charge at rest, it builds and looks for somewhere to go. The discharge can cause three types of damage: catastrophic, latent and upset failure.

How do you get rid of electrostatic discharge?

1. Add Some Moisture to Your Air. Water molecules reduce static electricity build-up, not just in your hair but also in your home. …
2. Treat Your Carpets with Anti-Static Spray. …
3. Stay Moisturized. …
4. When All Else Fails, Use Metal. …
5. Mr.

How do you get rid of static electricity in your body?

Ground Your Body The fastest way to get rid of static electricity in the body is to let the electricity do what it wants – discharge from your body into the ground. To allow this, touch any conductive material not isolated from the ground such as the screw on a light switch’s panel or a metal streetlight pole.

Article first time published on

What are the levels of ESD sensitivity?

ClassificationVoltage Range (V)1C1000 to < 200022000 to < 40003A4000 to < 80003B≥ 8000

How do you check for electrostatic discharge?

The charge can be measured by individual charge meter or by measuring the discharge curve from the charged device. From the discharge curve the discharged current, energy and charge can be calculated. There are no exact acceptance levels; they must be analyzed according to ESD sensitivity of the device in case.

What is contact discharge?

The contact discharge is the method of testing in which the electrode of the test generator is kept in contact with the EUT or coupling plane and the discharge is actuated by the discharge switch within the generator. … The IEC 61000-4-2 standard says “Contact discharge is the preferred test method.

What is the most common cause of ESD?

Causes. One of the causes of ESD events is static electricity. Static electricity is often generated through tribocharging, the separation of electric charges that occurs when two materials are brought into contact and then separated.

What are the types of ESD?

• Catastrophic Failures.
• Latent Defects.

What is ESD program?

The ESD Control Program Plan is the principal document for implementing and verifying the Program. The goal is a fully implemented and integrated Program that conforms to internal quality system requirements. The ESD Control Program Plan shall apply to all applicable facets of the Organization’s work.” [

What is meant by EMI and EMC?

EMI stands for electromagnetic interference and is an electronic emission that interferes with components, RF systems, and most electronic devices. … The difference between EMI and EMC is that EMI is the term for radiation and EMC merely is the ability for a system to operate within the presence of radiation.

What is EMI and EMC in PCB?

What are EMI and EMC in a PCB? Electromagnetic compatibility (EMC) is the ability of an electronic system to operate within an electromagnetic environment satisfactorily without generating intolerable EMI (electromagnetic interference) in nearby devices/systems.

Why EMC test is required?

EMC testing is necessary to help you meet regulatory requirements, improve product performance and reduce the risk of costly non-compliance. A third-party EMC test lab can conduct conformity assessments and also help to strengthen your competitive position in the market.

What is Surge test?

Surge voltage testing is used to discover insulation problems in wound materials. … A surge voltage test is the only testing method which can determine insulation problems in wound materials. In a surge voltage test, only the winding insulation against the earth/ground is tested.

What is EMC immunity?

EMC immunity testing measures the ability of a device to withstand different types of electromagnetic phenomena. … Because there is a wide range of potential EM phenomena, multiple types of immunity testing exist.

What is EMI EMC testing?

EMI/EMC testing is a critical step in bringing a new product to market. … Emissions testing – measures the amount of electromagnetic noise generated by a device during normal operation. The purpose of these tests is to ensure that any emission from the device are below the relevant limits defined for that type of device.

Why do I feel current in my hands when I touch something?

When you touch a doorknob (or something else made of metal), which has a positive charge with few electrons, the extra electrons want to jump from you to the knob. That tiny shock you feel is a result of the quick movement of these electrons.

Why is there so much static in my house?

It is directly affected by humidity. Static increases when the air gets cold and humidity drops. To stay warm in your home, you turn up the heat, further adding to a decrease in humidity and increasing static. While static can be annoying and sometimes painful, there are some simple things you can do to reduce it.

What happens when you have too much electricity in your body?

When nerves are affected by an electric shock, the consequences include pain, tingling, numbness, weakness or difficulty moving a limb. These effects may clear up with time or be permanent. Electric injury can also affect the central nervous system.

How many volts does it take to feel an electrostatic discharge?

ESD can also occur when a high electric field develops between two objects nearby. In a typical environment like your home, numerous ESD events can occur, most of which you do not see or feel. It takes a discharge of about 2,000 volts for a person to feel an electric “zap”.

What is latent failure in ESD?

Latent failures occur when ESD weakens or wounds the component to the point where it will still function properly during testing, but over time the wounded component will cause poor system performance and eventually complete system failure.

Is static electricity bad for the heart?

The charge will flow through your body causing an electric shock. This could cause burns or even stop your heart.

Why do I get a shock from everything I touch?

Static shocks are more common when it’s cold and dry. This dry, cold air holds less water vapour than warm summer air. … So, when you touch something like a metal doorknob or car door, those extra electrons will rapidly leave your body and give you the shock.

Why do I have more static electricity than others?

A bigger body, bigger feet, and thinner shoe soles, means more charge has to be stored to produce the same voltage. This gives a higher energy electrostatic discharge. Thirdly, you may be generating more charge than others. This may be due to the material of your shoe soles, or the way that you walk.

Why do I get shocked when I touch something?

Experiencing a light electrical shock when you touch another person, or at times even objects, is a result of something known as ‘static current. … Hence, the shock we feel is when electrons move quickly towards the protons.
